VaporTEK Calibration
5. When the display below appears, if necessary to change the pulse rate, press the keys shown:
VAPOR CONTROLLER
Pulse assignment
Cur:
Change with
6. Enter Pulse Rate 136 for Encore 500S/500/300 dispensers.

Auto-Calibration using FB1 Terminal

1. Press the Start button until below screen appears. Press the keys as shown:
2. When the display below appears, press the keys shown:
3. When the display below appears, press the keys shown to start the auto-calibration:
4. At the display below, select the dispenser side (1 or 2) that you want to calibrate:
10 Errors (1)
Production (2)
Fuel Flow (3)
Impulse (4)
050
F2
*** SERVICE ***
SAL – pump (1)
S&B – pump (2)
GIL – pump (3)
*** SERVICE ***
Gas measuring (1)
SYS–Identify (2)
EC2000 (3)
Service (1)
Parameter (2)
Autocalib (3)
Simulation (4)
4
Press number
keys to enter
F2
desired pulse
rate, e.g., 136
2
3
49
Auto-Calibration using FB1 Terminal
ENTER
