Communication Setup - VaporTEK Interface

Setup with Laptop

OFF
Switch off, tag, and lockout the 230V AC Main power to the VaporTEK-3 Controller board and wait at least 30
seconds for it to power down.
Connect your laptop to the VaporTEK-3 Controller board using the special USB Adapter flash adapter P/N: 141
057 636 as it's shown in Figure 22.
All necessary setup, such as pulse ratio and K-Factor, can be done by using a FB1-Service
Terminal.
VEEDER-ROOT
BR1
UNSAFE AREA
F1
X1
L
N
PE
M1
M2
M1 M2
L1
N PE
VAPORTEK-CONTROLLER
900890-001
V1
IC5
UNSAFE AREA
SAFE AREA
J1
J2
MOTOR
MOTOR
PE
POWER
SIGNAL
PE
X2
X3
RS422

Figure 22. VaporTEK USB-Adapter Service

V6
USB Service and Flash
Adapter cable plugs into
PROGRAM connector
V3 V8
VTEK3 Flash
Adapter
J3
X4
34
