Introduction

VaporTEK-3 Controller Board Kit - P/N 900895-001

Item
VEEDER-ROOT VAPORTEK-CONTROLLER
900890-001
BR1
IC5
J3
F1 J1
J2
MOTOR MOTOR
PE
POWER SIGNAL
X1
PE X2 X3 X4
RS422
L N PE M1 M2
Quantity
VaporTEK-3 Controller Board, P/N – SK 141 031 916;
1
P/N – VR 900890-001
1 VaporTEK-3 Controller board Mounting BRKT ASM, P/N 900892-001
1 VaporTEK-3 Controller board MTG Cover, P/N 900893--001
1 Label, VTEK-3 Controller KIT, P/N 900853-001
4 Snap Lock Standoff P/N 579197-001
2 Saddle Clamp – T15 #8 SPC, P/N 576010-834
9
Description
VaporTEK Kits
