Veeder-Root VaporTEK Installation, Setup And Troubleshooting Manual page 44

Communication Setup - VaporTEK Interface
13. Debug Modes: Press '4'
This sub-menu allows a debug mode selection. If fuel flow debug mode is selected the screen will show the
fuel flow rate when a transaction is running. Pressing 'f' again will disable the flow debug mode. During flow
debug mode no other mode can be activated.
Once the VaporTEK Pump Unit starts running the fuel flow and the related motor speed information will be
shown on the screen. Press the 'f' button again to disable this function.
Press 's' to show the power consumption data of motor.
New Connection Hyperterminal
File Edit View Call Transfer Help
4. Debug Mode
-------------------
Press 'f' to toggle to real time fuel Flow
Press 'd' to debug Motor Hall Sensor Signals
Press 's' to show the current Motor Speed
Connected 0:02:44 Auto detect 9600-8-N-1
New Connection Hyperterminal
File Edit View Call Transfer Help
************ Motor Data ***********
STATE SPEED POWER
RUN 0449 RPM 0013 Watts
RUN 0481 RPM 0026 Watts
RUN 0470 RPM 0019 Watts
Motor Data off
Status 2 Idle
Connected 0:02:44 Auto detect 9600-8-N-1
SCROLL CAPS NUM Capture Print echo
0220 V(DC) 0064 mA(DC)
0219 V(DC) 0128 mA(DC)
0220 V(DC) 0096 mA(DC)
SCROLL CAPS NUM Capture Print echo
40
Setup with Laptop
