Introduction
W = 140 mm
Outlet Port G 1/4"
Flame Arrester (1)
Flame
Arresters (2)
Inlet Ports G 1/4" (2)

VaporTEK Pump Specifications

Function
Flow medium
Flame Arrestors
Mounting
Motor Type
Voltage (Single Phase)
Frequency
Watts
Motor Speed
Maximum flow rate
Noise Level
Sensor Cable
M22 x 1.5,6g Hex
Cable Retainer (2)
Motor Cable
65 mm

Figure 3. VaporTEK Pump Dimensions

Gasoline vapor
Type: Ex IIA; Inlet & Outlet Ports
Four M6 X 1 Mounting Boss (Either side of the pump)
Synchronous BLDC (Brushless DC) Motor
230 VAC (±10%)
50/60 Hz
250W
2500 rpm max.
Up to 120 lpm
59 dB (A)
13
65 mm
Mounting Boss (4)
Both Sides (M6 x 1)
Flow Direction to UST
L = 245 mm
Description
VaporTEK Pump Characteristics
H = 235 mm
