AMCI Compatible Transducers
Table 1.2 lists the AMCI transducers compatible with the 1700 modules.
Model Shaft
R11X-J10/7 0.120"
R11X-J12/7 0.188"
HT-6 0.188"
HT-20 0.625"
HT-20S 0.625"
HT-20C 0.625"
HT-20K 0.625"
HT-20L 0.625"
H25-FE 0.375"
H25-FS 0.375"
H25-FL 0.375"
H25-SE 0.375"
H25-SS 0.375"
H25-SL 0.375"
HT-400,
0.625"
HT-400A,
HT-400B
HT-20-(X) 0.625"
HTT-20-1 0.625"
HTT-400-1 0.625"
0.047"
HTCR-9n-1
Cable
0.047"
HTCR-9n-6
Cable
0.047"
HTCR-9n-20
Cable
† Available gear ratios are: 2:1, 2.5:1, 2.77:1, 3:1, 4:1, 4.8:1, 5:1, 6:1, 7:1, 8:1, 9:1, 10:1, 12:1, 13:1, 15:1,
16:1, 20:1, 24:1, 36:1, 40:1, 50:1, 60:1, 64:1, 100:1, 105:1, 150:1,180:1, 250:1 and 256:1
‡ This package contains two resolvers geared 1:1 with the input shaft. Most commonly used in systems that
mandate redundant sensors, AMCI can install two different size 11 resolvers in the package per customer
requirements. Contact AMCI for more information.
1-4
