Advanced Micro Controls Inc. 1700 Series User Manual page 25

Chapter 2 Module Description
Module Setup Parameters (continued)
Transfer Type Pg. 1-8
PLC SERIES
Figure 2.14 Transfer
Type
PLC Program Pg. 1-8
PLC SERIES
Figure 2.15 PLC
Program
Single Transfer Length
PLC SERIES
Figure 2.16 Single
Transfer Length
Resolver Type Pg. 1-9
PLC SERIES
Figure 2.17 Resolver
Type
2-8
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Default: Block transfer
Range: Block
Single
Default: Read Only
Range: Read Only
Program Enabled
This parameter is only shown when the Transfer
Type parameter is set to block transfer. If Transfer
Type is set to single transfer, the Single Transfer
Length display is shown.
Pg. 1-9
Default: 16 bit
Range: 16 bit
32 bit
This parameter is only shown when the Transfer
Type parameter is set to single transfer. If Transfer
Type is set to block transfer, the PLC Program
display is shown.
Default: 1: AMCI resolvers
Range: 1: AMCI resolvers
2: Autotech Resolvers
ADVANCED MICRO CONTROLS INC
