Transducer Outline Drawings (continued)
H25FE: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
( ) = Dimensions in millimeters
1.032"
(26.21)
typ.
1.032"
(26.21)
typ.
1.250"
1.249"
2.65" max.
(67.3)
H25SE: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
( ) = Dimensions in millimeters
2.50"
(63.5)
1.250" (31.75)
1.249"
(31.72)
3-4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
0.218" dia.
(5.54)
Four places.
0.3747"
0.3744"
2.65"
(67.3)
(31.75)
2.50"
(63.5)
(31.72)
Figure 3.5 H25FE Outline Drawing
0.300"
0.3747"
0.3744"
2.31"
(58.64)
(22.86)
0.900"
0.850"
(21.59)
#8-32 UNF- 2B. 0.18" min depth. Six
(4.6)
places, 60° apart on a 1.875"
(47.63)
Figure 3.6 H25SE Outline Drawing
0.250"
0.300"
(7.62)
(6.35)
(9.517)
(9.510)
0.900" (22.86)
0.850"
(21.59)
2.35"
(58.8)
dia.
0.700"
(17.78)
Total clearance of 3.5"
needed for removal of
(7.62)
mating connector.
(9.517)
(9.510)
0.10"
(2.5)
0.10"
(2.5)
2.42"
B.C.
ADVANCED MICRO CONTROLS INC
0.700" max.
(17.78)
Total clearance of 3.5"
(89)
needed for removal of
mating connector.
max.
MS3102E16S-1P
Connector
max.
(89)
MS3102E16S-1P
Connector
max.
(61.5)
