Transducer Outline Drawings (continued)
H25FL: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
1.032"
(26.21)
typ.
1.032"
(26.21)
typ.
1.250" (31.75)
1.249"
(31.72)
2.65"
(67.31)
H25SL: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
2.50"
(63.5)
#8-32 UNF-2B.
1.250" (31.75)
0.18"
(4.6)
1.249"
(31.72)
Six places, 60° apart
on 1.875"
HT-6: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 13
1.50"
1.125"
(38.1)
(28.58)
C L
1.125"
(28.58)
3-6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
0.218" dia.
(5.54)
Four places
0.300"
(7.62)
(9.517)
0.3747"
0.3744"
(9.510)
2.65"
(67.31)
0.900" (22.86)
0.850"
(21.59)
2.50" dia.
(63.5)
( ) = Dimensions in millimeters
Figure 3.9 H25FL Outline Drawing
