Transducer Outline Drawings (continued)
H25FS: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
( ) = Dimensions in millimeters
2.65"
(67.3)
max.
1.032"
(26.21)
typ.
2.65"
H25SS: Anodized Aluminum Body, 303 Stainless Steel Shaft, NEMA 4
( ) = Dimensions in millimeters
2.65"
(67.3)
max.
1.250" (31.75)
1.249"
(31.72)
20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786
Tel: (860) 585-1254 Fax: (860) 584-1973
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1.13" max.
(28.7)
Total clearance of 3.5"
needed for removal of
mating connector.
2.65"
(67.3)
1.250" (31.75)
1.249"
(31.72)
1.032"
0.218" dia.
(5.54)
(26.21)
typ.
Four places
(67.3)
Figure 3.7 H25FS Outline Drawing
1.20" max.
(30.5)
Total clearance of 3.5"
for removal of mating connector.
0.3747"
0.3744"
2.31"
(58.6)
#8-32 UNF-2B.
0.18" min. depth.
(4.6)
Six places, 60° apart
on 1.875" B.C.
(47.62)
Figure 3.8 H25SS Outline Drawing
Chapter 3
1.43" sq.
(36.3)
(89)
0.300"
(7.62)
0.3747" (9.517)
0.3744"
(9.510)
0.900" (22.86)
0.850"
(21.59)
.250"
1.43" sq.
(89) needed
(36.3)
0.300"
(7.62)
0.300" (7.62)
(9.517)
(9.510)
0.900" (22.86)
0.10"
(2.5)
0.850"
(21.59)
0.10"
(2.5)
2.70"
Installation
MS3102E16S-1P
Connector
2.50"
(63.5)
(6.35)
2.65" max.
(67.3)
MS3102E16S-1P
Connector
2.50"
(63.5)
max.
(68.6)
3-5
