Advanced Micro Controls Inc. 1700 Series User Manual page 36

Transducer Cable Wiring Diagrams
C1T-(x) Wiring Diagram: For 1731 & 1741, (x) = length in feet
8
7
S3
6
S4
5
S1, S2
4
Shields
3
R2
2
R1
1
Module Connector
AMCI Part #: MS-8
Phoenix #:
C2T-(x) Wiring Diagram: For 1732 & 1742, (x) = length in feet
S3
8
S4
7
S3
6
S4
5
S1, S2
4
Shields
3
R2
2
R1
1
Module Connector
AMCI Part #: MS-8
Phoenix #:
20 Gear Drive, Plymouth Ind. Park, Terryville, CT 06786
Tel: (860) 585-1254 Fax: (860) 584-1973
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
BLK
WHT
GRN
BLK
SHIELDS
RED
BLK
BELDEN 9873 Cable
For cable lengths greater than
MSTB2.5/8-ST-5.08
100' (30 meters) use BELDEN 9730.
17 57 07 7
Figure 3.15 C1T-(x) Wiring Diagram
BLK
WHT
BLK
GRN
BLK
RED
BLK
WHT
BLK
GRN
SHIELDS
RED
BLK
MSTB2.5/8-ST-5.08
17 57 07 7
Figure 3.16 C2T-(x) Wiring Diagram
Chapter 3 Installation
F
F
BELDEN 9873 Cable (Two places)
For cable lengths greater than 100' (30 meters) use BELDEN 9730.
F
E D
G C
A B
Transducer
Connector
AMCI Part #: MS-16
Bendix #:
MS3106A16S-1S
E D
G C
A B
Transducer 2
Connector
AMCI Part #: MS-16
Bendix #:
MS3106A16S-1S
E D
G C
A B
Transducer 1
Connector
AMCI Part #: MS-16
Bendix #:
MS3106A16S-1S
3-9
