Understanding the display

These symbols display on all three controllers:
Symbol
P1, P2, P3, P4 Program 1, Program 2, Program 3, Program 4
M
T
MT
S
V
EA
H1
H2
H3
H4
H5
H6
In addition to the above, these symbols display on the Bodyworn
Controller:
Symbol
x
26 - Nucleus Freedom User Manual
Microphone
Telecoil
Microphone and Telecoil on at the same time
Sensitivity (ranges from 0 to 20)
Volume (ranges from 0 to 9)
External Accessory: flashes when accessory is
first turned on
Lines on left of display: processor programmed
for the left ear
Lines on right of display: processor
programmed for the right ear
Flat battery
Low battery
Coil error
Audio error
Program corrupted
Implant ID error (incorrect implant detected by
your processor)
External Accessory is activated
Sound level indicator sounds are being picked
up by your processor
Battery Level Indicator: battery power is full
One segment of Battery Level Indicator:
battery power is low
Meaning
Meaning
