Make sure the controller or shoe and Processing Unit are aligned
correctly, as even a slight misalignment can cause technical problems.
Check for broken or bent contacts between the controller or shoe
and the Processing Unit, which can cause misalignment. Return your
processor to your clinician if any contacts are bent or broken.
To attach the Bodyworn Cable to the controller:
1. Line up the dot mark on the plug with the dot mark at the top
of the controller.
2. Push the plug into the socket.
Dots lined up on connector and controller
To avoid damaging the cable, grip the connector as shown when
pushing the cable in, or pulling it out.

Wearing the Babyworn wearing option

The Babyworn wearing option consists of the Babyworn Retention
Case and Babyworn Cable. It provides comfort in the way children
wear the BTE Controller. The standard BTE Controller and
Processing Unit are connected with the Babyworn Cable. The
Babyworn Retention Case holds the BTE Controller.
