2-gang
standard push button sensor 'TSM'
Product name
2-gang standard push button sensor 'TSM'
Design:
flush-mounted (UP)
Article no.
2072 TSM
ETS search path
Push button / Push button 2-gang / 2-gang standard push button sensor 'TSM'
Issue:
21.09.2005
Functional description:
The 2-gang standard push button sensor 'TSM' is plugged onto a flush-mounted bus coupling unit (BCU) (cf.
connection diagram). After a press on the key, the push button sensor will transmit software-dependent telegrams
to the KNX / EIB. These may be telegrams for switching, pushbutton operation, dimming or for shutter control. It is
also possible to program value-transmitting functions such as dimming value transmitter or light-scene extension
units. A blue operation LED can serve as orientation lighting
Layout:
A
1
2
Technical Data
Type of protection:
Safety class:
Mark of approval:
Ambient temperature:
Storage / transport temperature:
Mounting position:
Minimum distances:
Type of fastening:
KNX / EIB supply
Voltage:
Power consumption:
Connection:
External supply
Product documentation
Dimensions:
Width:
Height: 70 mm (without
3
Depth: 7 mm (without PEI)
C
B
4
IP 20
III
KNX / EIB
-5 °C ... +45 °C
-25 °C ... +70 °C (storage above +45 °C reduces the lifetime)
any
none
plugging onto flush-mounted (BCU 1)
21 – 32 V DC (SELV) via flush-mounted BCU
typically 150 mW
2 x 5-pole pin contact strip
---
KNX/EIB
Controls:
70 mm (without
A: 2 rockers (keys 1 to 4: key-press
frame)
frame)
B: 2 status LEDs (red), one per
C: 1 operation LED (blue)
Page: 1 of 29
Sensor
on upper and lower half of
respective rocker)
The device is operated with the
corresponding push button
sensor module covers. The
covers must be ordered
separately:
2 x FD..902 TSA..
Covers with article nos.
FD..90x TSA NA.. can be
labelled. For labelling,
commercial-grade foils can be
printed with the JUNG inscription
software and inserted into the
keys.
rocker
