KNX
825 586 03
Stand: Jul-08
Operating Instructions
Touch sensor module Standard
1-channel, 2-channel, 3-channel, 4-channel
1. Safety warnings
Attention: Electrical equipment must be installed and fitted by
qualified electricians only.
Failure to observe any of the installation instructions may cause
damage to the device and result in fire or other hazards.
2. System Information
This device is a product of the KNX/EIB system and complies with KNX
directives.
Detailed technical knowledge obtained in KNX/EIB training courses is a
prerequisite to proper understanding. The functionality of this device
depends on the software.
Detailed information on loadable software and attainable functionality as
well as the software itself can be obtained from the manufacturer's
product database.
Planning, installation and commissioning of the unit is effected by means
of KNX-certified software.
An updated version of the product database and the technical
descriptions are available in the Internet at www.jung.de.
Touch sensor module Standard
Ref.-no.: 207x TSM
Advertisement
Related Manuals for Jung 2071 TSM
Summary of Contents for Jung 2071 TSM
- Page 1 Planning, installation and commissioning of the unit is effected by means of KNX-certified software. An updated version of the product database and the technical descriptions are available in the Internet at www.jung.de. 825 586 03 Stand: Jul-08...
- Page 2 Off / Darker / Down Together with the wall-mounted radio-control transmitter, Art. no. 40 FW, the device can also be used within the JUNG-Funk-Management system. More details are set out in the technical documentation of the wallmounted radio-control transmitter.
- Page 3 4.1. Label covers The covers with Art. no. FD..90x TSA NA.. can be equipped with labels. Commercial-grade transparencies can be inscribed with the help of the JUNG labelling software and inserted as labels into the covers.
-
Page 4: Technical Data
Touch sensor module Standard Ref.-no.: 207x TSM The JUNG labelling software is available in the Internet under the following address: www.jung-beschriftungsservice.de. Fit the label covers as shown in FIG 5. Technical data Supply: 21 – 32 V DC via flush-mounted...
