LB management
Brightness / temperature sensor Bluetooth
Brightness / temperature sensor Bluetooth
Art. no.: 1792HTBT
Operating instructions
1
Battery safety instructions
This device or its accessories are supplied with batteries in the form of button cells.
DANGER! Batteries can be swallowed. This can lead directly to death by suffocation. Danger-
ous substances may cause severe internal burns leading to death within 2 hours.
Keep new and used batteries away from children.
Do not use devices if the battery compartment does not close securely and keep away from
children.
If you suspect that a battery has been swallowed or is in any orifice of the body, seek immediate
medical attention.
WARNING! Improper handling of batteries can result in explosion, fire or chemical burn due to
leakage.
Do not heat or throw batteries into fire.
Do not reverse polarity, short-circuit or recharge batteries.
Do not deform or disassemble batteries.
Replace batteries only with an identical or equivalent type.
Remove empty batteries immediately and dispose of in an environmentally friendly manner.
These instructions are an integral part of the product, and must remain with the end customer.
2
Intended use
–
Sensor for detecting brightness and temperature
–
Operation with Bluetooth universal timer from LB management
–
Adhesive mounting in the interior on windows
3
Commissioning
Open the housing
￭
Open the housing by pushing it apart. To do so, insert a thin slotted screwdriver into the
opening recess (Figure 1) and raise it up so that two catches are passed.
82599913
J0082599913
Figure 1: Open the housing
1 / 5
11.11.2019
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Jung 1792HTBT
Summary of Contents for Jung 1792HTBT
- Page 1 LB management Brightness / temperature sensor Bluetooth Brightness / temperature sensor Bluetooth Art. no.: 1792HTBT Operating instructions Battery safety instructions This device or its accessories are supplied with batteries in the form of button cells. DANGER! Batteries can be swallowed. This can lead directly to death by suffocation. Danger- ous substances may cause severe internal burns leading to death within 2 hours.
- Page 2 LB management Brightness / temperature sensor Bluetooth Figure 2: Raise housing lid ￭ Push the housing apart as far as it will go. ￭ To remove the cover, it must first be lifted off on one side, e.g. with a small screwdriver (Figure 2).
- Page 3 LB management Brightness / temperature sensor Bluetooth Figure 5: Engaging the circuit board ￭ Note MAC address (3) (Figure 5). This address is required for assignment to the cover. ￭ Insert the circuit board in the housing base. Firstly, push the circuit board up to the front side of the housing and then push the rear section of the circuit board downwards (Figure 5).
-
Page 4: Technical Data
2.5 mW, Class 2 Conformity Albrecht Jung GmbH & Co. KG hereby declares that the radio system type art. no. 1792HTBT meets the directive 2014/53/EU. You can find the full article number on the device. The com- plete text of the EU Declaration of Conformity is available under the Internet address: www.jung.de/ce... - Page 5 LB management Brightness / temperature sensor Bluetooth ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de www.jung.de 82599913 11.11.2019 5 / 5 J0082599913...
