Njoy Garun Series User Manual

3 phase in / 3 phase out ups
Hide thumbs Also See for Garun Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Garun Series
3 Phase IN / 3 Phase OUT UPS
UP33TOP110KGAAZ01B
UP33TOP115KGAAZ01B
UP33TOP120KGAAZ01B
UP33TOP130KGAAZ01B
Before using this product, carefully read all product documentation and retain it for future reference.
User Manual
UP33TOP140KGAAZ01B
UP33TOP160KGAAZ01B
UP33TOP180KGAAZ01B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Garun Series and is the answer not in the manual?

Questions and answers

Related Manuals for Njoy Garun Series

Summary of Contents for Njoy Garun Series

  • Page 1 Garun Series User Manual 3 Phase IN / 3 Phase OUT UPS UP33TOP110KGAAZ01B UP33TOP140KGAAZ01B UP33TOP115KGAAZ01B UP33TOP160KGAAZ01B UP33TOP120KGAAZ01B UP33TOP180KGAAZ01B UP33TOP130KGAAZ01B Before using this product, carefully read all product documentation and retain it for future reference.

  • Page 2: Table Of Contents

    3. Operations ......................17 3-1. Initial operation ......................17 3-2. Screen description ....................17 3-2.1. Main screen ....................18 The following models belong to the Garun Series: 3-2.2. Control screen ....................18 3-2.3. Measure screen ..................... 20 10K VA Garun 10KL 3-2.4.

  • Page 3: Safety And Emc Instructions

    Safety and EMC instructions All safety instructions in this document must be read, understood and followed. 1.1. Transportation and storage • Please transport the UPS system only in the original packaging to protect against shock and damage. • The UPS must be stored in the room where the temperature is well regulated.

  • Page 4: Connection Warnings

    1.4. Connection warnings Before working on this circuit 1. Isolate Uninterruptible Power Supply (UPS) • There is no standard backfeed protection inside of the UPS. However, 2. Then check for Hazardous Voltage between all terminals including the there are relays on the Input to cut off line voltage and while the neutral is protected earth.

  • Page 5: Installation And Operation

    Installation and operation 2.1. Unpacking and inspection Unpack the package and check the package contents. The shipping package should contain: • One UPS • One user manual • One monitoring software CD • One RS-232 cable (option) • One USB cable •...
  • Page 6 Diagram 6: Garun 60KL Diagram 7: Garun 80KL Front view with door open Front view with door open Diagram 3: Garun 30KL Diagram 4: Garun 40KL Rear panel Rear panel Diagram 8: Garun 60KL, 80KL Dual Input / Output terminal Diagram 5: Garun 30KL, 40KL Dual Input / Output terminal...

  • Page 7: Single Ups Installation

    2.3. Single UPS installation • The cable for Garun 60KL should be able to withstand over 120A current. It is recommended to use AWG 4 or thicker wire for Phase and AWG 1 or Installation and wiring must be carried out in accordance with the local thicker wire for Neutral for safety and efficiency.

  • Page 8: Ups Installation For Parallel System

    • Set the battery pack breaker in “OFF” position and then install the battery pack. • Pay high attention to the rated battery voltage marked on the rear panel. If you want to change the numbers of the battery pack, please make sure you modify the setting simultaneously.

  • Page 9: Software Installation

    Operations 3.1. Initial operation Step 1. Before operation, make sure that the two strings of batteries are connected correctly in order of ”+,GND,-” terminals and the breaker of the battery pack is at “ON” position (only for long-run model). Step 2. POWER button to set up the power supply for the Press the UPS.
  • Page 10 3.2.1. Main screen ON/OFF UPS It will show “Turn on UPS?” when UPS is off. Upon powering on, the LCD will start initialization approximately few It will show “Turn off UPS?” when UPS is on. seconds. Touch “YES” to turn on or off the UPS. Then, the screen will return to main screen.
  • Page 11 Audio mute It will show “Mute all” if the audio is active. Touch “Yes” to activate mute. If “Mute all” is active, it will show icon on the top left corner of the main screen. Touch “Back” to return to CONTROL screen immediately or “No” to cancel this operation and back to CONTROL screen.
  • Page 12 GENERAL: It’s to set up basic information of the UPS. It’s not related to any function parameter. ADVANCE: It’s required to enter password to access to the “ADVANCE” setting. There are two types of authority, User and Maintainer. SAVE SETTING: This function is reserved for future. General Measure screen page 3 INPUT W: R, S and T input power in watt.
  • Page 13 Advance - User To access “Advance-User” settings menu page, the default password is “0000”. If entered password is right, the page will jump to setting screen. If the password is wrong, it will ask to enter again. General Setting page 2 Audio Alarm: There are two events available to mute.
  • Page 14 • ELECTRONIC Bypass FREE Range: Set the bypass frequency range. The acceptable bypass frequency range from 46Hz to 54Hz when UPS is 50Hz system and from 56Hz to 64Hz when UPS is 60Hz system. ECO mode: Enable/Disable ECO mode. Default setting is “Disable”. ECO Voltage Range: Set the ECO voltage range.
  • Page 15 Battery Parameter: Advance - Maintainer Battery AH: setting battery capacity. • Miscellaneous Advance: Maintainer Setting Menu Page1 Miscellaneous setting page Auto Restart: (This function is reserved for future use) Enable: After “Enable” is set, once UPS shutdown occurs due to low battery and then utility restores, the UPS will return to line mode.
  • Page 16 • SYS Parameter SYS Parameter page 2 SYS Parameter page 1 • Install info Mode Name: Set the UPS model name. Serial Number: Set the serial number. Manufacturer: Set the UPS manufacturer. Charger Number: The number of charging boards installed in the UPS NOTE! INSTALL INFO It’s required to restart the UPS after setting.
  • Page 17 • VOL CALI VOL CALI Page3 VOL CALI Page1 Inverter VOL: Inverter voltage calibration. Bypass VOL: Bypass voltage calibration. Bus VOL: BUS voltage calibration. BATT VOL: Battery voltage calibration. • CURR CALI CURR CALI VOL CALI Page2 CURR CALI Page Line VOL: Line voltage calibration.
  • Page 18 • Initial INITIAL PARAMETERS page INITIAL menu page PARAMETERS: After pressing the confirmation window, it will pop up as shown in above screen. Touch “YES” to restore default value. Touch “Back” or “No” to cancel this operation and back to INITIAL menu page. INITIAL DATALOG page DATALOG: After pressing, the confirmation window, it will pop up as shown in above screen.
  • Page 19 • ELECTRONIC INITIAL EEPROM page Electronic Setting page 1 EEPROM: After pressing the confirmation window, it will pop up as shown in above screen. Touch “YES” to clear all setting value in EEPROM. Touch “Back” Output Voltage: Select the output rated voltage. There are four options: or “No”...
  • Page 20 • Battery Electronic Setting page 2 Bypass at UPS off: Select the bypass status when manually turning off the Battery setting page UPS. This setting is only available when “Bypass forbid” is set to “Disable”. Battery Warning Voltage: Enable: Bypass enabled. When selected, bypass mode is activated. Disable: Bypass disabled.
  • Page 21 • Miscellaneous • UPS Selftest UPS Selftest Page Miscellaneous setting page This function is only effective when UPS type setting is “HV”. Therefore, Auto Restart: please disconnect all loads and utility first before executing this function. Enable: After “Enable” is set, once UPS shutdown occurs due to low Then, please change UPS type to “HV”.
  • Page 22 3.2.5. Information screen SYS Install Date: The date of system installation. BAT Install Date: The date of battery installation. Touch the icon to enter information page. Touch the icon PAR State: The information of parallel state. browse information. Touch the icon to return to main screen.
  • Page 23 • Parameter information BATT Warning Voltage: HIGH: High battery warning voltage. LOW: Low battery warning voltage. Shutdown Voltage: If battery voltage is lower this point, UPS will automatically shut down. Battery Age: It shows battery age. Battery AH: It shows battery AH Battery Number: It shows battery number.

  • Page 24: Audible Alarm

    3.3. Audible alarm 3.2.6. Data Log screen Description Buzzer status Muted Touch the icon to enter data log page. Data log is used to record the UPS status warning and fault information of the UPS. The record contains date & time, code, type and description.
  • Page 25 • In Battery mode, users can touch “SETTING” ► “Basic” ► Audio Mute to POWER button to set up the power supply for the UPS. UPS will • Press the enable “Mode Mute” to disable the buzzer. enter to power on mode. After initialization, UPS will enter to No Output mode. •...

  • Page 26: Parallel Operation

    • Some warning alarms can’t be muted unless the error is fixed. Please refer meter. Calibrate the inverter output voltage by configuring inverter voltage to section 3-3 for details. adjustment (Refer to SETTING ► VOL CALI screen) in LCD menu until the inverter output voltage difference of each UPS is within 1V or less.

  • Page 27: Fault Code

    3. Remove units from the parallel system 3.6. Fault Code There are two methods to remove units from the parallel system: Fault code Fault event Fault code Fault event • First method: a) Touch “CONTROL”► “Turn off UPS” and select “Yes” to turn of Bus start failure Overload the UPS.

  • Page 28: Warning Code

    3.7. Warning Code Inverter relay short Battery polarity reverse circuited Warning Warning PFC IGBT over-current Warning event Warning event Line wiring fault code code in A phase Line situations are different in Parallel communication PFC IGBT over-current Battery unconnected parallel system failure in B phase Bypass situations are...

  • Page 29: Troubleshooting

    Problem Possible cause Solutions Troubleshooting The UPS shut Fault code is down automatically Check output wiring and if If the UPS system does not operate correctly, please solve the problem by shown as 14, because short circuit connected devices are in short using the table below.

  • Page 30: Storage And Maintenance

    • Do not attempt to dispose of batteries by burning them. This could Storage and maintenance cause battery explosion. The batteries must be deposed according to local environmental regulations. 5.1. Storage • Do not open or destroy batteries. Escaping electrolyte can cause injury to the skin and eyes.
  • Page 31 DAI-TECH SRL 28 Popa Șapcă 300057, Timișoara Romania declare that the products UPS Garun Series: UP33TOP110KGAAZ01B, UP33TOP115KGAAZ01B, UP33TOP120KGAAZ01B, UP33TOP130KGAAZ01B, UP33TOP140KGAAZ01B, Disposal of Old Electrical & Electronic Equipment UP33TOP160KGAAZ01B, UP33TOP180KGAAZ01B (Applicable in the European Union and other European countries with separate...
  • Page 32 Memo Memo...
