Master Programming Mode
Entering Master Programming Mode
‐To enter Master Programming Mode press and hold both buttons for 5 seconds.
1. Regeneration Time (r)
Press the Menu/Enter Button. The next display viewed is the option setting for
Regeneration Time. It is identified by the letter 'r' in the left digit. Set the desired time
of day that a regeneration may occur, if required. We recommend setting the system to
backwash at 2 AM, or at any time that it is unlikely that any water will be used. The first
digit(s) indicates the Hour and the other digit indicates A.M. or P.M..
Example: 2 A.M. regeneration time ‐ [ r 2A ] (factory setting)
2. Regeneration Cycle Step Programming (1)(2)(3)
The next 3 displays viewed are part of a series of option settings used to program the
Regeneration Cycle. Up to 4 steps can be programmed, however, some steps may not
be necessary for your application and will be set to 0. Each display is used to set the
duration time in minutes for that specific step in a regeneration cycle. A step # will turn
on for the regeneration cycle step being programmed. Regeneration steps are skipped
by setting the display to 0 as shown below:
Examples: Regeneration Cycle Step #1 ‐ 10 minutes ‐ [ 1 ‐ 10 ] (Factory Setting)
Regeneration Cycle Step #2 ‐ skipped ‐ [ 2 ‐ ‐ 0 ]
Set each step according to the values below, appropriate for a carbon filter:
1 10 minutes. This is the Backwash cycle. [ 1 ‐ 10 ]
2 0 minutes. This is the Brine Draw cycle, not used on your valve. [ 2 ‐ 0 ]
3 6 minutes. This is the Rapid Rinse cycle. [ 3 ‐ 6 ]
3. Blue Tooth (This feature is not used in your application; it is for rental units)
After Cycle Step Three above, when you press the menu/enter button, the display will
show bE 1 ; press the menu/enter button again, the display shows: bTPP and then
changes to 1234. Press the menu/enter button, and now you are back to the home service
screen (displaying the clock time and the number of days until backwash).
Exiting the Master Programming Mode
Press the Menu/Enter Button until all steps have been viewed. The Program Mode will
be exited and normal operation resumed. If no buttons are pressed for 60 seconds or
longer in Master Programming Mode, it will be exited automatically.
