Pro-OX 5700-E Iron Filter Installation
& Start-Up Guide
Thank you for purchasing a Clean Water System! With proper installation and a little
routine maintenance your system will be providing iron free water for many years.
Please review this start‐up guide entirely before beginning to install your system, and
follow the steps outlined for best results.
USE PAPER MASK AND VENTILATE AREA TO AVOID BREATHING DUST DURING
Questions?
Call us toll‐free: 1‐888‐600‐5426 or 1‐831‐462‐8500
Email us:
support@cleanwaterstore.com
See more information on our website:
PRO-OX MEDIA CONTAINS DUST.
INSTALLATION
www.cleanwaterstore.com/resources
Clean Water Made Easy
http://www.cleanwaterstore.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pro-OX 5700-E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clean Water Systems Pro-OX 5700-E

Summary of Contents for Clean Water Systems Pro-OX 5700-E

  • Page 1 Clean Water Made Easy http://www.cleanwaterstore.com Pro-OX 5700-E Iron Filter Installation & Start-Up Guide Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing iron free water for many years.

  • Page 2: Table Of Contents

    Pro-OX 5700-E Iron Filter Installation & Startup Guide Table of Contents Packing List ..............................3 Pre-Installation ............................. 4 Best Practices for Piping & Drain Installation ....................4 How Your Iron Filter Works ......................... 5 Assembly and Installation Instructions ......................8 Programming ..........................

  • Page 3: Packing List

    Pro-OX 5700-E Iron Filter Installation & Startup Guide Packing List 0.75 Cubic Foot Size System Quantity (1): CWS 5700-E control valve w/ bypass assembly and pipe connector kit (1” or 3/4”) Quantity (1): 8” x 44” standard filter tank with distributor tube Blue media funnel for adding Pro-OX media 12 lbs.

  • Page 4: Pre-Installation

    A minimum of 20 PSI is required; maximum pressure is 90 PSI. 4. Get all of your plumbing parts together before beginning installation. Installation typically takes 3 to 5 hours, though the Pro-OX 5700-E iron filter must also be allowed to run through a complete backwash and rinse cycle after installation.

  • Page 5: How Your Iron Filter Works

    Pro-OX 5700-E Iron Filter Installation & Startup Guide 7. The drain line tubing (not supplied) is connected to a drain from the drain outlet using flexible 1/2” ID tubing. Note that the drain can run up above the CWS 5700-E control valve and into a drain—it does not have to drain down, as the filter backwashes under line pressure from your well pump.
  • Page 6 Pro-OX 5700-E Iron Filter Installation & Startup Guide Fig. 2—Typical Pro-OX 5700-E iron filter piping installation with ball valve and hose bib after filter www.cleanwaterstore.com Rev 090514 Page 6...
  • Page 7 Pro-OX 5700-E Iron Filter Installation & Startup Guide Fig 3—CWS 5700-E valve from the rear showing the inlet (left) and outlet (right) end-connector fittings (1” or 1-1/4” NPT in Noryl plastic). Brass end-connectors are also available for connecting to copper tubing.

  • Page 8: Assembly And Installation Instructions

    Pro-OX 5700-E Iron Filter Installation & Startup Guide Assembly and Installation Instructions 1. By hand, unscrew the entire CWS 5700-E control valve from top of tank if it was shipped screwed on. Place distributor tube in tank if not already inside. Make sure the tube is capped, or wrap the top of the tube with electrical or duct tape.
  • Page 9 Pro-OX 5700-E Iron Filter Installation & Startup Guide Fig. 5—CWS 5700-E Service and Bypass Knob Positions 10. Lubricate the bypass valve O-rings with some vegetable oil or silicone grease and connect the bypass assembly to the control valve by sliding the bypass valve firmly into its body.
  • Page 10 Pro-OX 5700-E Iron Filter Installation & Startup Guide Optional Side Tank Installation Fig. 6: Optional Side Tank Installation 15. Insert 3/8” diameter tubing into the chlorine side tank connection. Screw the nut with the sleeve and Ferrell attached to prevent leaking.

  • Page 11: Programming

    Pro-OX 5700-E Iron Filter Installation & Startup Guide Normal Operation Programming: Time Mode: Home screen will display days and hours left until the unit regenerates. Meter Mode: Meter mode tracks the number of gallons used instead of regenerating on a specific time.
  • Page 12 Pro-OX 5700-E Iron Filter Installation & Startup Guide Meter & Timed Meter Menus: The following menus will allow you to change the current time, unit hardness, and calendar day override settings within the Meter and Timed Meter Modes. Current Time settings: Press the gear to begin menus.
  • Page 13 Pro-OX 5700-E Iron Filter Installation & Startup Guide Meter and Time Meter Menus continued.. Calendar Day Override setting: Allows user to set a time to regenerate by if the unit hasn’t met its set meter amount within that time period.
  • Page 14 Pro-OX 5700-E Iron Filter Installation & Startup Guide Time Menus The following menus will let you change the Current Time and the Regeneration Day for Time Mode only. Current Time settings: Press gear to begin menus. Current time and period of the day will be flashing.
  • Page 15 Pro-OX 5700-E Iron Filter Installation & Startup Guide Time Menus Continued.. Using the up and down arrows, you can set the number of days you wish to have between regenerations. The unit has a range of 1-99 days. Default setting is 7 days.
  • Page 16 Pro-OX 5700-E Iron Filter Installation & Startup Guide Advanced Menus Continued.. After selecting the mode, the time of day the unit is set to regenerate will appear. Pressing the Regen button will allow the time to be changed. Use the up and down arrows to adjust the hours and A.M.
  • Page 17 Pro-OX 5700-E Iron Filter Installation & Startup Guide Advanced Menus Continued.. Total minutes the unit draws brine will be flashing. Unit can be set anywhere from 0-99 minutes. If you don’t have the optional side tank, set to 0 This menu displays Rapid Rinse settings.
  • Page 18 Pro-OX 5700-E Iron Filter Installation & Startup Guide Advanced Menus Continued.. This last menu is to change the unit’s capacity. Unit has a range of 1-199 Capacity (for Meter and Timed Meter Modes only). Multiply capacity setting by 1000 to get grains.
  • Page 19 Pro-OX 5700-E Iron Filter Installation & Startup Guide Restore Factory Settings Hold the Regen button while plugging in the power supply to the unit. After the unit has powered up release Regen button. Next press the Regen button again to select no next to reset.

  • Page 20: Troubleshooting The Pro-Ox 5700-E Iron Filter

    Pro-OX 5700-E Iron Filter Installation & Startup Guide Troubleshooting the Pro-Ox 5700-E0 Iron Filter Measure the backwash flow rate by putting the system into a backwash mode and putting the drain tube into a 5 gallon bucket and timing the flow rate. A 0.75 cubic foot system should flow at 5 gallons in one minute, so the 5 gallon bucket should fill in one minute.
