DEMO MANUAL DC1238B

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 1 C1
3 1 R1
4 1 R2
5 1 R3
6 1 U1
Additional Demo Board Circuit Components
1 1 C4
2 0 C3, C5 (OPT)
Hardware For Demo Board Only
1 1 E1, E3-E7
2 1 JP1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X5R, 4.7μF, 6.3V, 10%, 0603
CAP., X7R, 1μF, 50V, 10%, 0805
RES., CHIP, 19.1k, 1/16W, 1% ,0402
RES., CHIP, 0Ω, 1/16W, 1% ,0603
RES., CHIP, 51.1k 1/16W, 1% ,0603
I.C., LTM8021EV#PBF, LGA, 15 PIN
CAP., SMT, 10μF, 50V
CAP., 0603
TESTPOINT, TURRET, 0.095"
2MM SINGLE ROW HEADER, 3 PIN
MANUFACTURER/PART NUMBER
AVX, 06036D475KAT2A
MURATA, GRM21BR71H105K
VISHAY, CRCW040219K1FKED
VISHAY, CRCW06030000Z0ED
VISHAY, CRCW060351K1FKED
LINEAR TECH., LTM8021EV#PBF
SANYO, 50CE10BSS
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-103-02-L-S
dc1238bf
