AMP Research PowerStep 75155-01A Installation Manual page 8

Insert plastic push pin rivets in mounting
holes of Motor Cover.
22
Drill a 9/32" hole through the pinch weld at marked
locations. Debur all holes.
24
Affix lamp to rocker panel surface. Make sure lamp
is affixed to a flat, clean surface.
26
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
10
– 4 R U N N E R
T M
On each side of the vehicle measure from the front
edge of door line on the pinch weld to the specified
lengths below. Measure at 24" for front LED Light
and 53" for rear LED LIght.
24"
23
Insert grommet into drilled holes. Insert lamp wires
through the grommets. (Silicon lube will help wires
slip through grommets.)
18
25
Using supplied butt connectors, connect the lamp
wires. Red to Red, Black to Black. Once Crimped
use heat gun to shrink tube.
27
8/9
53"
19
20
IM75155 rev 01.09.19
