APPLICATION

Chevy Tahoe / GMC Yukon / Cadillac Escalade

Chevy Suburban / GMC Yukon XL / Escalade ESV

Chevy Avalanche / Escalade EXT

AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST

Designed and manufactured by AMP Research

5-year limited warranty. Professional installation is recommended.

www.amp-research.com

I N S T A L L A T I O N G U I D E

. Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221;

1/10

MODEL YR

2007 - up

INSTALLATION TIME

1 2 3

PART #

75124-01

75125-01

3:00

hrs

SKILL LEVEL

4= Experienced

TOOLS REQUIRED

Safety goggles

Measuring tape

Flat blade screwdriver

Phillips head screwdriver

Right angle drill

9/32" drill bit

13 mm socket

10 mm socket

7 mm socket

Ratchet wrench and extension

13mm end wrench

Wire stripper / cutter

Pliers

Corrosion inhibiter

3/16" hex key wrench (allen wrench)

5mm hex key wrench (allen wrench)

Electrical tape

Weather proof caulking (silicone

sealer)

IM3274 rev 06.08.10

Need help?

Do you have a question about the PowerStep 75124-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for AMP Research PowerStep 75124-01

Page 1 Designed and manufactured by AMP Research ® . Patent Number 6,830,257; 6,641,158; 6,834,875; 6,938,909; 6,942,233; 7,007,961; 7,055,839; 7,163,221; 7,367,574; 7,380,807; 7,398,985; 7,413,204; 7,487,986. Other US and Worldwide patents pending. Made in USA © 2010 AMP Research 5-year limited warranty. Professional installation is recommended. www.amp-research.com 1/10 IM3274 rev 06.08.10...
Page 2 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T PARTS LIST AND HARDWARE IDENTIFICATION (A) 19-03225-11 End cap left (x1) (B) 19-03225-12 End cap right (x1) (C) 19-02663-90 T-nut insert (x2) (D) 19-03236-90 Socket cap screw (x2)
Page 3 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T PARTS LIST AND HARDWARE IDENTIFICATION 19-02849-90 19-02389-90 19-03326-90 Hex Bolt...
Page 4 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 6:00 AM - 5:00 PM PST Designed and manufactured by AMP Research. Patent 6,830,257 / 6,641,158 / 6,834,875 / 6,938,909 / 6,942,233 / 7,007,961 Other US and worldwide patents pending. 5-year limited warranty. Professional installation is recommended.
Page 5 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T Bolt idler linkage assembly to rearmost Bolt driving linkage assembly to forward mounting tab using an M8 nut and washer most mounting tab using an M8 nut and...
Page 6 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T Route long end of wire harness above engine Route wire harness along the frame.
Page 7 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T Using Supplied Posi-Tap™ connector, splice Remove plastic trim on door near shorter trigger wire into wire found in Step12.
Page 8 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T Pull back the door weather guard, unbolt Feed longer wire of Step 11 through tube into speaker and unplug.
Page 9 A M P R E S E A R C H P O W E R S T E P – G M C / C H E V R O L E T Slide motor assembly onto drive shaft and Replace power fuse.
Page 11 L IMI T ED WARRAN T Y AMP RESEARCH warrants product to be free from defects in material and workmanship, for terms speci ed below, provided there has been normal use and proper maintenance. All remedies under this warranty are limited to the repair or replace- ment of any item found by the factory to be defective within the time period speci ed.
