AMP Research PowerStep 75155-01A Installation Manual page 2

A
F
1
x2
Running board assembly
2
Driver Motor
Linkage Assembly
5
Wire Harness
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
(A) End cap left (x1)
(B) End cap right (x1)
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
(F) End cap wedge left (x1)
3
Passenger Motor
Linkage Assembly
6
Controller STA
– 4 R U N N E R
T M
2/9
C
E
D
B
4
x2
Idler Linkage
Assembly
7
x8
Socket Cap Screw
IM75155 rev 01.09.19
