AMP Research PowerStep 75155-01A Installation Manual page 4

Locate forward most set of threaded holes on
the frame. Located just behind front body mount.
1
Pre thread upper M10 flange head bolt onto
frame mount. Slide linkage into position and
thread in lower flange head bolt.
3
Locate Rear most set of threaded holes on the
frame just forward of rear suspension. Vehicle
shown has Vehicle Stability Control lines. Tighten
screws to 16 ft-lbs.
5
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
17
16
– 4 R U N N E R
T M
Using provided flat head cap screws attach frame
mount extrusion to front set of threaded holes.
Torque screws to 16 ft-lbs.
2
Snug bolts to allow for adjustment at a later step.
4
Pre thread upper M10 flange head bolt onto
frame mount. Slide linkage into position and
thread in lower flange head bolt. Motor faces
front of vehicle.
6
4/9
17
17
16
IM75155 rev 01.09.19
