Mocka Urban Buffet Assembly Instructions Manual

Urban Buffet
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B1
bolt & 50mm 30mm
nut x30 screw x16
screw x12
E F
E3
E4
E1
E2
dowel
slide
rail x4 x20
L
K
wall
wall
anchor x2 strap x2
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
B2 C1 C2
12mm 18mm
screw x10
screw x24
G H I
wedge
feet 25mm
x10
x4 screw x2
N O
M
bracket 12mm
cover
x2 x2 screw x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in
D certain circumstances, i.e. if a child attempts to climb up on the furniture or in the event
of an earthquake. Accordingly, we recommend that all furniture is anchored to a wall.
We supply a free safety wall anchor with all furniture sold and we recommend these
are used to prevent your product tipping. The fixing device provided should fit most
wall types, but please note that different wall materials may require different fixing
devices from those supplied.
50mm
screw x14
J
14mm
screw x2
P
stopper
x2
Phillips & Flathead screwdrivers and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
