Mocka Urban Entertainment Unit Assembly Instructions Manual

Urban Entertainment Unit
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B1
bolt & 50mm 30mm
nut x30 screw x12 screw x16
E F
E3
E4
E1
E2
dowel
slide
x20
rail x4
L
K
wall wall
anchor x2
strap x2
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
B2 C1 C2
12mm 18mm
screw x10
screw x24
G H I
wedge
feet 25mm
x10 x4 screw x2
N O
M
cover bracket 12mm
x2 screw x2
x2
Hardware Supplied
WARNING: Any furniture that is not anchored to a wall has the potential to
D
tip over in certain circumstances, i.e. if a child attempts to climb up on the
furniture or in the event of an earthquake. Accordingly, we recommend that
all furniture is anchored to a wall. We supply a free safety wall anchor with all
furniture sold and we recommend these are used to prevent your product
tipping. The fixing device provided should fit most wall types, but please note
that different wall materials may require different fixing devices from those
supplied.
50mm
screw x14
J
14mm
screw x2
P
stopper
x2
Phillips & Flathead screwdrivers and hammer required
use of a power drill on a low-speed setting.
For quicker assembly, we recommend the
1
