Urban Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B1
bolt &
50mm
30mm
nut x12
screw x8
screw x16
E
F
E3
E4
E1
E2
slide
dowel
x12
rail x2
L
K
wall
wall
anchor x2
strap x2
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
B2
C1
C2
18mm
12mm
screw x12
screw x4
G
H
I
wedge
feet
25mm
x4
x4
screw x2
N
O
M
cover
bracket
12mm
x1
screw x1
x1
WARNING:
Any furniture that is not anchored to a wall has the potential to tip
D
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
50mm
screw x8
J
14mm
screw x2
P
stopper
x1
Phillips & Flathead screwdrivers and hammer required
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
