1.1

Acronyms

1.2

Features

AT89STK-09 User Guide
This document helps the user to get started with the AT89STK09 starter kit.
The AT89STK09 is a starter kit for the AT83C26 device. The AT83C26 is a smart card
reader interface with 2 DC/DC converters allowing to manage up to 5 smart cards
including level shifters. This device needs TWI commands to configure its registers. This
device requires a host microcontroller (Smart Card Reader Microcontrollers, ARMs, ...)
with one or two ISO7816 Smart Card Interfaces.
Refer to the AT83C26 datasheet for further product information.
• TWI : Inter Integrated Circuit
• SCIB: Smart Card Interface Bus
• LDO : Low Drop Output (Regulator)
The AT89STK-09 Board provides the following features:
• AT89STK09 board with 2 ISO7816-3 connectors and 4 SIM/SAM connectors
• 2 Gemplus GemClub Smart cards
• One 20 multicolor wires cable with HE10 connector
• Smart Card Reader IC CDROM (from may 2005)
• 2 VQFP48 & 2 QFN48 samples
• AT89STK09 user guide document
The AT89STK09 board allows a large number of hardware configurations.
Section 1

Introduction

7521B–SCR–10/05
1-2
