Hardware
2.4
Test Points
2-7
7521B–SCR–10/05
CVCC2
CVCC3
Caution : Active probe use is recommended to measure all smart card interfaces signals
SIgnal
DC/DCB
CVCC1
CVCC4
CVCC5
AT89STK-09 User Guide
