1.1

Features

AT89STK-03 Hardware User Guide
This document describes the MCU demonstration board included in AT89STK-03
Starter Kit dedicated to the AT8xC5122 & AT83C5123 Smart Card Reader
microcontrollers.
This board enables to test the microcontrollers by using demonstration software and/or
start the developement of applications.
The AT8xC5122 & AT83C5123 demonstration board provides the following features:
Support of three packages :
– PLCC 68
– VQFP 64
– PLCC 28
On-board configurable power supply using a low drop regulator powered by :
– an external power converter
– an external battery
– the USB interface
ISO7816 Smart Card connector
SIM Smart Card connector
On-board reset, INT1, In-System Programming and USB detach switches
EEPROM 24C256 socket for code storage
Power, ALE, RS232 Rx /Tx, and 7 general purpose LEDs
USB, SPI and RS232 hardware connectors
Test points
Two 48x2 headers
