Operation and installation manual
(PVI-STRINGCOMB (-S, -MC, -S-MC) - Rev:1.0)
To set the weight of every string, carry out the following procedure:
Carry out the following operations in conditions of fixed light so that the
parameters will be constant.
Automatic method
a) Choose, by selection (using the arrow shown in the figure), a
reference string, the weight of which will be maintained always at 1.
b) Press [Auto-Factors]. The program will calculate the weights of all
strings automatically.
Manual method
a) Choose a reference string, the weight of which will be maintained
always at 1.
b) Calculate the weight of the other strings by dividing the current of
every string by that of reference.
c) Note down the weights of every string and set them on the right hand
panel.
Manually set the weights of the unused strings at 0.
Then press [Set I-Factors >>] to save the new "weights". A confirmation
window of the new settings will appear.
Check that the operation has been carried out correctly and then press
[OK]: if there are any errors, press [OK] and then repeat the operation.
Press the button
screen.
to close the window and return to the StringComb Monitor
Page 81 of 96
