Symbols used on the PVI-STRINGCOMB(-S)

The device has various labels; those with a yellow background regard the safety
devices provided.
Make sure that you have read and fully understand the labels before installing the
device.
The symbols used on the device, referring to electrical parts, are the following and
they are also used in this Manual:
Connection point for the earth conductor
+
Continuous positive voltage pole
-
Continuous negative voltage pole
Direct Current (DC)
Grounding (GND)
