Operation and installation manual
(PVI-STRINGCOMB (-S, -MC, -S-MC) - Rev:1.0)
Every device can be powered by an external source (24V DC). This allows the
PVI-STRINGCOMB(-S) to remain running also during the night.
PSPs are available in four different versions. The differences are the
presence or not of the switch disconnector and the string connection type.
PSPs should be configured when placing the order using the
configuration model that can be found on the internet at the following
address:
String-combs can be configured in different ways according to:
• Number of strings that can be connected
• Cable gland type or MC4 string input connector type
• Size of fuses
• Parallel string output cable gland
• Cable gland for the ground cable
More information are available on the website.
Figure 4-2 shows an example of the connection, by means of PVI-
STRINGCOMB(-S), of a 100kw centralised AURORA inverter to a photovoltaic
field composed of 2 arrays (photovoltaic field A and B), each in turn consiting of 4
strings.
www.stringcombconfigurator.com
