Operation and installation manual
(PVI-STRINGCOMB (-S, -MC, -S-MC) - Rev:1.0)
-
STRING 2
STRING 1
+
Connection of the strings
(10) Monitor panel menu: the following figures show the construction of the
main menus:
Figure 12-5: Current / weight reading panel
Value of current on string
no.8
Weight of current on
string no.5
Choice of "advanced" or "standard"
mode and return to the Manager
(Paragraph §12.5).
Return directly to the
Manager (Paragraph §12.5).
Page 76 of 96
