- Page 1 Saber Conference Installation Instructions...
- Page 2 Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration. • NOTE: Sightline Tables use different width Bases for the narrow end versus the middle and wide end of the table.
- Page 3 Required Tools • Phillips Head Screwdriver • ¼” Allen Wrench • 5/32” Drill Bit...
- Page 4 Step 1: End Base Installation • Loosen (Do not remove) 5/16” cap screws attached to clamp Bars. • Slide main beams into position with the clamp bars aligned in the slots of the main beam. – NOTE: For sightline with center column base only shorter beams mounted between wider bases.
- Page 5 Step 2: Center Base Installation • For tables 168” and longer slide (2) main beams together onto the clamp bars positioning such that the (2) main beams meet in the center of the base. Using the Allen wrench, tighten cap screws. •...
- Page 6 Step 3: Top and Base Panels • and beam structure. Center top using the “L” shape marks on the Place top onto the base underside of the top as a guide. Pre-drill holes corresponding to the top attachment brackets. • Attach base and beam structure to top using #12 x 1”...
