TESANO CONFERENCE TABLE
(current) 5-2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the TESANO and is the answer not in the manual?

Questions and answers

Related Manuals for Nucraft TESANO

Summary of Contents for Nucraft TESANO

  • Page 1 TESANO CONFERENCE TABLE (current) 5-2015...

  • Page 2: Before Beginning Installation

    For 96” tables and larger it is recommended to have 3 or 4 people available for the install. • These instructions reflect typical assemblies; They may not match your specific configuration  Note: This table will be assembled right-side up Tesano...
  • Page 3 Required Tools & Hardware  Drill Driver  #2- Phillips Bit  Laser Level  ¼” Allen Wrench Tesano...
  • Page 4 Tesano Conference Tesano...
  • Page 5 Tesano Exploded 1. Work Surface 2. Top Beams 3. Mending Plate 4. Base 5. Rail Key 6. Wire Management 7. Power Rail Tesano...
  • Page 6  Insert the beams with rail keys attached, into each of the bases  Use labels to attach correct beams to correct bases Note: Dowels are not needed in the base ends Tesano...
  • Page 7  Place top onto beams, sliding one end into the pins (hardware #4) and dowels (hardware #6) of one base  Repeat with the base on the opposite end  Make sure the ends match labels Tesano...
  • Page 8  Slide the bases tight to the top and tighten cams fully.  Attach mending plate along the center of the metal spacer. Pilot holes should be present.  Attach smaller mending plates in between the edge of the table and the top wood rails. Tesano...
  • Page 9  The beams will be secured by inserting a screw at the bottom of the slotted openings found along one face of the beam  Using the bolts shown at right insert into side of rail key and secure Tesano...
  • Page 10 Step 5 Fastening Aprons  Locate the aprons between the inside of the side rail and the black beam, and fasten them using supplied silver screws (hardware #2)  Locate notch, place in apron toward end of table Tesano | 10...
  • Page 11 Step (2): Join the two sides Step 6 of the table together with a connector receptacle Installing Wire Management Step (1): Attach wires to receptacles Step (3): Use the hardwires to connect to an electrical output through the end of the base Tesano | 11...
  • Page 12 (hardware #3).  The label will be facing the top  The silver screws (hardware #1) must be used on the raised surface, while the black screws (hardware #3) should be used on the lower surface Tesano | 12...
  • Page 13  The silver bolts should be inserted into the bracket before inserting into rail.  Place power unit over screws  Tighten nuts to secure unit to the rail. Tesano | 13...
