Page 2
Tools Required and Initial Notes Hardware Included Tools Required For Assembly • 2 People • BOLT, 3/8” UNC x 5/8” L-HW2248 • Phillips Head Screwdriver • BOLT, 5/16-18 x 5/8 Flt Socket head • Drill with #2 and #3 Phillips bit cap (Post Leg Base ONLY) •...
Page 4
FLOW NT Table Flow Component Description 1. Work Surface 2. End Base 3. Center Base 4. Main Beam...
Page 5
Installation Step 1 – For tables over 120” (if your table is 120” or less skip to step 3) • Loosen the clamp bars from the base – DO NOT remove. • Locate the labels and match the beams to the correct placement on the bases 1/8”...
Installation Step 2 & 3 • Using a level on the main beam, assure that the base is sitting level. Adjust the glides as necessary to assure that the base is level before proceeding. • Align the top with the corners of the bases utilizing the “L”...
Installation Step 1 & 2 • Slide the clamp bars from the end base into the main beam. • Tighten the screws that fasten the end base to the main beam. • Attach the main beam to the center base per the photo to the right.
