  • Page 1 Tesano Installation Instructions...

  • Page 2: Before Beginning Installation

    Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly. Tables longer than 96” require 3-4 persons. • These instructions reflect typical assemblies. They may not match your specific configuration.

  • Page 3: Required Tools

    Required Tools • Drill Driver • #2-Phillips Bit Hardware 1 • Laser Level • ¼” Allen Wrench Hardware 2 Hardware 3 Hardware 4 Hardware 5 Hardware 6...
  • Page 4 Tesano Conference...
  • Page 5 Tesano Conference Exploded Work Surface Top Beams Mending Plate Base Rail Key Wire Management Power Rail...
  • Page 6 Step 1: Connecting Rails to Bases • Run glides out of bases before beginning assembly. • Loosen bolts (hardware #6) in the keys attached to the beam. • Insert the beams with rail keys attached, into each of the bases with the “THIS SIDE UP” label facing up and pilot holes facing ground.
  • Page 7 Step 2: Installing Top • Insert pins (hardware #4) into the holes along the top edge of base end. • Place top onto beams, sliding one end into the pins of one base. • Repeat with the base on the opposite end. •...
  • Page 8 Step 3: Securing Top with Mending Plates NOTE: Ensure to center sides of top to the bases prior to attaching mending plates. Square the base up to the top before securing the mending plates. • Attach mending plate along the center of the metal spacer. Pilot holes should be present. •...
  • Page 9 Step 4: Securing Top Rails • With the mending plates secured in place, secure the top beams to the wood rails using hardware #5 long silver screws. The pilot holes in the beam should be facing the ground. • Using cap screws (hardware #6) shown below, insert into side of rail keys.
  • Page 10 Step 4: Securing Top Rails • Center the top beam between the base and the tighten cap screws ensuring bottom of beams are flush with on another. • Secure the top beams to the wood rails using hardware #5 long silver screws. The screws will go through the slotted openings along the face of the beams.
  • Page 11 Step 5: Fastening Aprons • Locate notch, place in apron toward end of table. • Place the aprons between the inside of the side rail and the black beam, and fasten them using supplied silver screws (hardware #2). Screws will go THROUGH the aluminum extrusion.
  • Page 12 Step 6: Installing Wire Management • Attach jumpers to receptacles • Run the jumpers around the table, in a U-shape design. • At one end of the table, the plug in-feed or hardware should run through the leg. Plug-in Infeed Jumper Jumper...
  • Page 13 Step 7: Installing Wire Management Covers • Locate the wire management channels. • Ensuring that the power duplex lines up with the cutout, fasten the wire management channel using silver screws (hardware #1) and black screws (hardware #3). • The label will be facing the top. •...
  • Page 14 Step 7: Installing Power Rail Units • The power rail unit will come with the two black brackets which should be inserted first into the rail. • The silver bolts should be inserted into the bracket before inserting into rail. •...
