Two4Six Media Table
Installation Instructions
ID:

Advertisement

loading
Need help?

Need help?

Do you have a question about the Two4Six and is the answer not in the manual?

Questions and answers

Summary of Contents for Nucraft Two4Six

  • Page 1 Two4Six Media Table Installation Instructions...
  • Page 2: Before Beginning Installation

    Before Beginning Installation • Read through the entire instruction thoroughly • A minimum of 2 persons is required for this assembly • These instructions reflect typical assemblies. They may not match your specific configuration.
  • Page 3: Required Tools

    Required Tools • Drill Driver • #2 and #3 Phillips Bit • Level...
  • Page 4: Base Options

    Base Options NOTE: Two different base styles may be used on one work surface.
  • Page 5 Top Shapes...
  • Page 6 Two4Six Media Table Credenza Base with Open Frame Leg Credenza Base with Open Frame Leg and Monitor Panel...
  • Page 7 Step 1: Set Up Credenza • Place the Credenza in the desired final location. • NOTE: These steps are for Monitor Panel Stations: • Insert the stanchions into the back of the credenza. • Loosen the glides at the bottom of the stanchions. The glides should be fully extended, as they will be adjusted later.
  • Page 8 Step 2A: Attach Legs (Open Frame Leg) • Once the Credenza is fully assembled, start working on the top. • Gently place top upside down on a soft, padded surface. • Open Frame Base – Align the predrilled holes in the top with the holes in the base and secure with screws. •...
  • Page 9 Step 2B: Attach Legs (Post Leg) • Gently place top upside down on a soft, padded surface. • Per customer’s desired location, attach the legs either in the standard or inset locations. – Align the holes in the top plate of the leg to the two predrilled holes in the top. –...
  • Page 10 Step 3A: Attach Work Surface to Credenza Base • Credenza Base – Set top on credenza and align the predrilled holes in the top with the slots in the plates on the credenza. – Insert the adjustment knobs and adjust the top location to the customer’s preference.
  • Page 11 Step 3B: Attach Slab Base • Slab Base is open on the back side, which should be against a wall. • Electrical wires should be run from the work surface, between the base and the wall, to the outlet. • Attach the slab base frame to a structural wall with monarch clips.
  • Page 12 Step 3B: Attaching Slab Base (cont) • The removable panel on the slab base is attached using • One of these individual parts is attached on the steel frame at 4 locations. • A second metal clip is attached to the panel. •...
  • Page 13 Step 3B: Attaching Slab Base (cont) • Once secured to the wall, insert the work surface attachment plate into the cutout and attach it with screws. • When all electrical routing is complete, secure L-brackets to the top with thumbscrews. •...
  • Page 14 Step 3C: Attaching Wall Mount • The open leg frame should be attached at one end of the table. • Using the provided brackets, secure the opposite end of the table directly into the wall. • Ensure that the fasteners are secured into a stiff material, such as a stud. HW0741...
  • Page 15 Step 4: Level Table • Place level on top, running along the length of the top. • Check for levelness and extend or retract glides as needed. • Repeat the above procedure along the width of the top. • Double check both directions. NOTE: Glides are located at these locations for adjustment.
  • Page 16 Step 5: Installing Power Rail (if applicable) • Insert thumbscrews into predrilled holes on the bottom of the table top. • Part can be attached at ends or along the length of the table. • Additionally the power rail can be adjusted toward or away from the edge of the table.
