INSTALLATION
Model W
LPM-4216 44 1/4"
LPM-5416 56 1/4"
LPM-6616 68 1/4"
LPM-7816 80 1/4"
1. Prepare the framed opening according to the
chart above. Provide a dedicated flexible 15
amp 120 volt circuit for hard wire installation.
4. Mask the exposed fire unit during the
drywall process. Install drywall to the drywall
stops on the perimeter of the fire box. For
more information on the drywall stops see the
Product Guide on page 4. Decorate as desired.
5. Install the side and front glass pieces.
H D
25 1/4" 12"
25 1/4" 12"
25 1/4" 12"
25 1/4" 12"
2. Install L Metal Nailing Flanges.
3. Install the fire unit in the framed opening with a
minimum 1 ¼ drywall screws to secure the unit.
