4. Parts Identification & Accessories
TG-10STX
Power On/Off switch
1
LED Display
2
Channel Selector
3
Set button
4
Volume control
5
Monitor volume control
6
1/8" Stereo Phone Jack
7
Antenna
8
DC input ( 12~18V 600mA )
9
Balanced Loop Out Connector CH.1
10
Balanced Loop Out Connector CH.2
11
Balanced XLR/Ø6.3mm Combo
12
Input Left / CH.1
Balanced XLR/Ø6.3mm Combo
13
Input Right / CH.2
BNC Antenna Output Socket
14
Monitor input(mono Ø6.3mm phone jack)
15
Input CH1 48V phantom power switch
16
1
3
8
2
3
4
5
7 6
3
15
16
9
10
11
12
13
14
TG-10STX
