Compaq StorageWorks Reference Manual page 24

10. Tighten the thumbscrew into the spring-loaded rack rail.
11. Align the rear of the storage enclosure rails with the front end of the spring-loaded
rack rails, then push it fully into the rack. Tighten the front panel thumbscrews.
CAUTION: Be sure to keep the component parallel to the floor when sliding the
storage enclosure into the spring-loaded rack rails. Tilting the component up or down
could result in damage to the rails.
Figure 3–5: Inserting the enclosure into the rack
12. Plug an external SCSI cable from the SCSI controller to the SCSI connector on
the back of the chassis.
13. Repeat step 12 for each SCSI controller in your system.
14. Plug the AC power cord into the power cord connector.
StorageWorks by Compaq 3U Rackmount Enclosure Reference Guide
Rack Installation
3–5
