Tape Drive Installation

Cable Configurations

Depending on the drive installed in the 3U Rackmount Enclosure, the cable
configuration will vary. If you have more than two tape drives in your storage
enclosure, you will need an additional cable kit and two SCSI ports.
The table below describes different tape drives with their supported cable
configurations.
Table 2–1: SCSI Cable Configurations
Tape Drive
AIT
DAT
DLT
SDLT
DAT AutoLoader

Installing SCSI Connectors

The 3U Rackmount Enclosure ships with two internal LVD wide SCSI cables attached
to the SCSI connector panel. Up to two additional SCSI cables can be installed in the
storage enclosure.
2–4
SCSI Cable Configuration
Up to 2 drives per SCSI cable
Up to 2 drives per SCSI cable
1 drive per SCSI cable
1 drive per SCSI cable
1 autoloader per SCSI cable
