Tape Drive Installation
To install additional SCSI connectors:
1. Loosen the three thumbscrews on the rear panel .


2. Slide the top panel toward the rear and pull the top panel off .

1
3
2
Figure 2–3: Removing the top panel
3. Take out the screw located on the outside of the unit.

4. Remove the blank panel from the inside of the unit.

4
5
Figure 2–4: Removing the external screw and internal blank panel
