Identifying Internal Components
Figure 1–5: Storage enclosure internal components
Fan assembly
Internal LVD/SE Wide SCSI cables (2)
Power supply
StorageWorks by Compaq 3U Rackmount Enclosure Reference Guide
1
2
6
3
Power switch and LED cable
Power switch assembly
Slide-out drive trays (2)
Introduction
4
5
1–5
