3.2.28 DC_P2, Video Expansion Connector
The DC_P2 is a 120 pin SAMTEC high speed connector allows the user to interface to
the video logic on the TMS320DM6467 EVM. The pinout for the pins 1-60 of the
DC_P2 connector are shown in the table below.
Table 17: DC_P2, Video Expansion Connector, Pins 1-60
Pin #
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
47
49
51
53
55
57
59
* VIDEO_OUT_EN0 disables on board video port low VPIF_DOUT0 - VPIF_DOUT7
and VPIF_CLKOUT2 when pulled high.
** VIDEO_OUT_EN1 disables on board video port low VPIF_DOUT8 - VPIF_DOUT15
and VPIF_CLKOUT3 when pulled high.
3-24
Signal
NC
GROUND
NC
GROUND
VPIF_DOUT1
VPIF_DOUT3
VPIF_DOUT5
VPIF_DOUT7
GROUND
VPIF_DOUT9
VPIF_DOUT11
VPIF_DOUT13
VPIF_DOUT15
GROUND
VIDEO_OUT_EN1 **
GROUND
VPIF_CLKIN3
GROUND
VPIF_CLKOUT3
GROUND
PTSI_CLK
GROUND
DC_VOXO_CLK_EN
DC_VOXO_CLK
GROUND
UART0_RIN
UART0_DSRn
UART0_CTSn
UART0_TXD
Pin # Signal
2 VPIF_CLKOUT2
4 GROUND
6 NC
8 GROUND
10 VPIF_DOUT0
12 VPIF_DOUT2
14 VPIF_DOUT4
16 VPIF_DOUT6
18 GROUND
20 VPIF_DOUT8
22 VPIF_DOUT10
24 VPIF_DOUT12
26 VPIF_DOUT14
28 GROUND
30 VIDEO_OUT_EN0 *
32 GROUND
34 VPIF_CLKIN2
36 GROUND
38 VPIF_CLKIN2_EN
40 GROUND
42 STSI_CLK
44 GROUND
46 DC_ALT_VOXO_EN
48 DC_ALT_VOXO
50 GROUND
52 UART0_DCDn
54 UART0_DTRn
56 UART0_RTSn
58 UART0_RXD
60 UART0_EN
