Spectrum Digital TMS320DM6467 Technical Reference

Evaluation module
Hide thumbs

Advertisement

Quick Links

Download this manual
TMS320DM6467
Evaluation Module
Technical
Reference
2007
DSP Development Systems

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMS320DM6467 and is the answer not in the manual?

Questions and answers

Related Manuals for Spectrum Digital TMS320DM6467

Summary of Contents for Spectrum Digital TMS320DM6467

  • Page 1 TMS320DM6467 Evaluation Module Technical Reference 2007 DSP Development Systems...
  • Page 3 TMS320DM6467 Evaluation Module Technical Reference 509535-0001 Rev. A July 2007 SPECTRUM DIGITAL, INC. 12502 Exchange Drive, Suite 440 Stafford, TX. 77477 Tel: 281.494.4505 Fax: 281.494.5310 sales@spectrumdigital.com www.spectrumdigital.com...

  • Page 4: Important Notice

    IMPORTANT NOTICE Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any product or service without notice. Customers are advised to obtain the latest version of relevant information to verify that the data being relied on is current before placing orders.
  • Page 5 ......Provides you with a description of the TMS320DM6467 Evaluation Module, key features, and block diagram.
  • Page 6 ........... . Describes the physical layout of the TMS320DM6467 Evaluation Module and its connectors.
  • Page 7 Module (EVM). The EVM is based on the Texas Instruments TMS320DM6467 Processor. The TMS320DM6467 Evaluation Module is a table top card that allows engineers and software developers to evaluate certain characteristics of the TMS320DM6467 processor to determine if the processor meets the designers application requirements.
  • Page 8 Related Documents, Application Notes and User Guides Information regarding this device can be found at the following Texas Instruments website: http://www.ti.com Table 1: Manual History Revision History Alpha Release Table 2: Board History History Revision Alpha Release...
  • Page 9 Chapter 1 Introduction to the TMS320DM6467 EVM Chapter One provides a description of the TMS320DM6467 EVM along with the key features and a block diagram of the circuit board. Topic Page Key Features Functional Overview Basic Operation Memory Map Configuration Switch Settings...
  • Page 10 Spectrum Digital, Inc 1.1 Key Features The TMS320DM6467 EVM is a PCI based or standalone development platform that enables users to evaluate and develop applications for the TI DaVinci processor family. Schematics, list of materials, and application notes are available to ease hardware development and reduce time to market.
  • Page 11 Two on board standard video decoders, one high definition video decoder, and on board standard video and high definition video encoder interface video streams to the TMS320DM6467 processor. Dual TVP5147 decoders, one TVP7002, and an on board ADV7343 six channel encoder are standard on the EVM and directly interface to on chip video ports.
  • Page 12 Composer communicates with the board through the embedded emulator or an external JTAG emulator. To start, follow the instructions in the Quick Start Guide to install Code Composer. This process will install all of the necessary development tools, documentation and drivers. TMS320DM6467 EVM Technical Reference...
  • Page 13 Refer to the appropriate device data sheets for more details. The memory map shows the address space of a TMS320DM6467 processor on the left with specific details of how each region is used on the right. By default, the internal memory sits at the beginning of the address space.
  • Page 14 DSP's I/O buffers and other chips on the board. The +1.8 volt supply is used for TMS320DM6467 DDR2 interface, and DDR2 memory. There are multiple power test points on the EVM. The three main test point pairs provide a convenient mechanism to check the EVM’s current for each supply.

  • Page 15: Board Components

    2-12 2.12 CPLD 2-13 2.12.1 CPLD Register 0, I/O Control, 0x3A 2-13 2.12.2 CPLD Register 1, Video Control, 0x3B 2-14 2.12.3 CPLD Register 2, CPLD Revision, 0x3C 2-14 2.13 TMS320DM6467 CPU Core Clock 2-15 2.14 TMS320DM6467 Core Voltage Select 2-15...
  • Page 16 Flash and ATA interface is disabled on board. 2.2.2 VLYNQ Interface The TMS320DM6467 brings its internal VLYNQ interface out to a 50 pin Samtec FTSH style connector JP1. The VLYNQ interface is implemented as a down stream peripheral and supports four transmit and receive channels.
  • Page 17 Spectrum Digital, Inc 2.2.3 UART Interface The internal UART0 on the TMS320DM6467 device is driven to connector P1. The UART’s interface is routed through CBT’s to a Texas Instruments MAX3243 RS-232 line driver prior to being brought out to a male DB-9 connector, P8. The on board UART signals can be disabled by pulling the UART0_EN signal high via the daughter card connectors.
  • Page 18 Spectrum Digital, Inc 2.5 Video Interfaces The TMS320DM6467 EVM has a 16 bit divideable video input port and 16 bit dividable output port to support a variety of user applications. Both ports can be used as two eight bit ports when the appropriate interface only requires 8 bits. High definition interfaces require all 16 bits.The EVM incorporates dual TVP5147 decoders or a...
  • Page 19 Spectrum Digital, Inc 2.5.2 Video Output Port Interfaces The TMS320DM6467 EVM has a 16 bit wide video output port which directly interface to an ADV7343 encoder. The video output ports are actually two 8 bit ports which are combined into a single 16 bit port for high definition video applications.
  • Page 20 The sample rate generator in the AIC32 is set by I C command codec registers. The figure below shows the codec interface on the TMS320DM6467 EVM. AIC32 Codec MIC IN...
  • Page 21 Spectrum Digital, Inc 2.6.1 Audio PLL/VCXO Circuit/CDCE949 Clock Generator The TMS320DM6467 EVM implements a multiple PLL clock generator via the CDCE949 for creating the audio and optional video clocks for the board. In streaming video applications the audio and video sequences can lose synchronization.
  • Page 22 Spectrum Digital, Inc 2.7 Ethernet Interface The TMS320DM6467 integrates an GMII/MII ethernet MAC on chip. This interface is routed to the on board PHY via CBT switches. The EVM uses an Agere ET1011C PHY. The interface is isolated and brought out to a RJ-45 connector with integrated magnetics, J4.
  • Page 23 2.9 I C Interface The I C bus on the TMS320DM6467 is ideal for interfacing to the control registers of many devices. On the TMS320DM6467 EVM the I C bus is used to configure the video decoder, stereo Codec, I/O expanders. An I C ROM is also interfaced via the serial bus.
  • Page 24 This eeprom is also used to store the ethernet MAC address and the board’s revision. The MAC address is also labeled on the board. Care should be taken not to erase these items when user information is stored in the eeprom. Spectrum Digital uses addresses 0x7F00 to 0x7FFF for manufacturing information. This information is shown in the table below.

  • Page 25: Spi Eeprom

    SPI_ENABLE daughter card pin when the pin is pulled high. 2.10 S/PDIF Analog, and Optical Interfaces The McASP1’s AxR[0] pin on the TMS320DM6467 can be configured to operate as a S/PDIF transmitter. The TMS320DM6467 EVM supports both analog and optical interfaces.
  • Page 26 Chapter 3. Table 4: Daughter Card Interfaces Interface Name Function DC_P1 Ethernet Interface Connector DC_P2 Video Expansion Connector DC_P3 I/O Expansion Connector Other than the buffering, most daughter card signals are not modified on the board. 2-12 TMS320DM6467 EVM Technical Reference...
  • Page 27 Spectrum Digital, Inc 2.12 CPLD The on board CPLD incorporates glue logic and I C control registers to minimize logic on the EVM. The CPLD incorporates 3 control registers at addresses 0x3A, 0x3B, and 0x3C. The table below specifies the functions of the I C control registers.
  • Page 28 The table below shows the bit definitions of CPLD register 2 at address 0x3C on the C bus. The bits in this register represent the revision of the CPLD. Table 8: CPLD Register 3, Version, 0x3C Bit # Name Description Version ID Current CPLD Revision 2-14 TMS320DM6467 EVM Technical Reference...
  • Page 29 TMS320DM6467 device. 2.14 TMS320DM6467 Core Voltage Select The TMS320DM6467 EVM has the ability to adjust the core voltage between 1.2 volts and 1.05 volts. GPIO6 and GPIO7 from the DM7467 are used to enable these pins when they are enabled during the boot sequence via the boot switch.
  • Page 30 Spectrum Digital, Inc 2-16 TMS320DM6467 EVM Technical Reference...

  • Page 31: Physical Description

    Chapter 3 Physical Description This chapter describes the physical layout of the TMS320DM6467 EVM and its interfaces. Topic Page Board Layout Connectors 3.2.1 J1, HD Component Video In, (Pb) 3.2.2 J2, HD Component Video In, (Y) 3.2.3 J3, HD Component Video In, (Pr) 3.2.4...
  • Page 32 3-28 3.4.1 SW1, Power On Reset Switch 3-28 3.4.2 SW2, 4 Position User Readable 3-29 3.4.3 SW3, Bootload Configuration Select 3-29 3.4.4 SW4, Power On Switch 3-31 3.4.5 S1, EMU0/1 Select Switch 3-32 Test Points 3-33 TMS320DM6467 EVM Technical Reference...
  • Page 33 Spectrum Digital, Inc 3.1 Board Layout The TMS320DM6467 EVM is a 10.0 x 4.2 inch (254 x 107 mm.) fourteen (14) layer printed circuit board which is powered by an external +5 volt only power supply. Figure 3-1 and Figure 3-2 show the layout of the TMS320DM6467 EVM.
  • Page 34 Spectrum Digital, Inc Figure 3-2, TMS320DM6467 EVM, Interfaces Bottom Side TMS320DM6467 EVM Technical Reference...
  • Page 35 Spectrum Digital, Inc 3.2 Connectors The EVM has twenty nine (29) interfaces to various peripherals. These interfaces are described in the following sections. Table 1: Connectors Connector Size Function HD Video In, Component (Pb) HD Video In, Component (Y) HD Video In, Component (Pr)
  • Page 36 3.2.1 J1, HD Component Video In, (Pb) J1 is an RCA input jack used to bring a channel of HD component (Pb) video to the TMS320DM6467 EVM. This signal is input to the TVP7002 codec. The pinout of this connector is shown below.
  • Page 37 Spectrum Digital, Inc 3.2.4 J4, Ethernet Interface The J4 connector is used to provide an 10/100/1000 Mbps Ethernet interface. This is a standard RJ-45 connector. The cable end pinout for the J4 connector is shown in the table below. Table 2: J4, Ethernet Interface...
  • Page 38 Spectrum Digital, Inc 3.2.6 J6, 14 Pin External JTAG Connector The TMS320DM6467 EVM is supplied with a 14 pin header interface, J6. This is the standard interface used by JTAG emulators to interface to Texas Instruments DSPs. The pinout for the connector is shown in the figure.
  • Page 39 Spectrum Digital, Inc 3.2.8 J8, Emulation Header, 20 Pin ARM The J8 emulation 20 pin header is located on the top side of the board and is used to provide an interface to ARM JTAG emulators. The pinout for the J1 connector is shown in the table below.
  • Page 40 J12 is an RCA jack used to provide High Definition component video (Pb) output to a video monitor. This connector is driven directly by the ADV7343 via an THS7303 driver. The pinout of this connector is shown below. Shield (ground) Signal Output Figure 3-10, J12, RCA Jack 3-10 TMS320DM6467 EVM Technical Reference...
  • Page 41 Spectrum Digital, Inc 3.2.12 J13, Composite Video In J13 is an RCA jack used as a video input to the TVP51467 video decoder. This connector brings in a video signal to the TVP5147. Do NOT plug into this connector with the power on. The figure below shows this connector as viewed from the card edge.
  • Page 42 Connector J15 is the input power connector. This connector bring in +5 volts to the EVM. This is a 2.5 mm. jack. The figure below shows this connector as viewed from the card edge. Ground PC Board Front View Figure 3-12, J15, +5 Volt Input Connector 3-12 TMS320DM6467 EVM Technical Reference...
  • Page 43 Spectrum Digital, Inc 3.2.15 P1, RS-232 UART Connector The TMS320DM6467 EVM has an RS-232 connector which brings out the UART0 transmit, receive, and control signals to be used as UART. This UART uses the MAX3243 RS-232 line driver and is routed to a male 9 pin D-connector, P1. The pin positions for the P1 connector as viewed from the edge of the printed circuit board are shown below.
  • Page 44 3.2.17 P3, S/PDIF Out (Optical) P3 is an optical transmitter connector used as an output from the McASP1 AxR[0] signal on the TMS320DM6467 DSP. This connector brings out an optical S/PDIF signal. Do NOT plug into this connector with the power on.
  • Page 45 Spectrum Digital, Inc 3.2.19 P5, Stereo Line Output Connector The P5 connector is provides a stereo output from the TVL320AIC32 on the EVM. The upper connector is the left channel, and the lower connector is the right channel. A view of the connector from the card edge is shown in the figure below. The signals present on this connector are defined in the following table.
  • Page 46 Left Pin 2 (upper) Pin 1 Right Pin 3 (lower) Figure 3-17, P6, Line In/Mic Interface Table 10: P6, Line In/Mic Interface Pin # Signal Input Isolated Ground LINE1L LINE2L 3-16 TMS320DM6467 EVM Technical Reference...
  • Page 47 Spectrum Digital, Inc 3.2.21 P7, S-Video In Connector P7 is a four pin mini din S-video connector which interfaces to the TVP5147 encoder. This connector brings in a video signal (LUMA) to pin 9 on the TVP5147. Do NOT plug into this connector with the power on. The figure below shows this connector as viewed from the card edge.
  • Page 48 Command/Byte Enable0 +3.3 Volts Not Used I/O/Z Address/Data 6 I/O/Z Address/Data 4 Ground I/O/Z Address/Data 2 I/O/Z Address/Data 0 +V I/O Not Used REQ64- Not Used +5 Volts +5 Volts Power +5 Volts +5 Volts Power 3-18 TMS320DM6467 EVM Technical Reference...
  • Page 49 Spectrum Digital, Inc The signals on the “B” side of the connector are shown in the table below. Table 13: P9, PCI Connector, “B” Side Signal Description Signal Description -12 Volts Not Used Not Used Ground Tied to TDO +5 Volts...
  • Page 50 Spectrum Digital, Inc 3.2.24 U2, IR Interface Interface U2 provides an Infrared interface to the TMS320DM6467 EVM. This is a receiver only for consumer remote controls. The view of U2 is shown from a board edge view in the figure below.
  • Page 51 Spectrum Digital, Inc 3.2.25 JP1, Downstream VLYNQ Connector The JP1 is a 50 pin SAMTEC FTSH-125-01-L-DV-EJ-K connector which allows the user to connect the VLYNQ interface to up stream VLYNQ interfaces. The pinout for the JP1 connector is shown in the table below.
  • Page 52 ATA RESETn ATA.DD7 ATA.DD8 ATA.DD6 ATA.DD9 ATA.DD5 ATA.DD10 ATA.DD4 ATA.DD11 ATA.DD3 ATA.DD12 ATA.DD2 ATA.DD13 ATA.DD1 ATA.DD14 ATA.DD0 ATA.DD15 ATA.DMARQ ATA.DIOW ATA.DIOR ATA.IORDY ATA_CSEL, TP34 ATA.DMACK ATA.INTRQ ATA.DA1 TP33 ATA.DA0 ATA.DA2 ATA.CS0 ATA.CS1 ATA.DASPn VCC_5V VCC_5V 3-22 TMS320DM6467 EVM Technical Reference...
  • Page 53 3.2.27 DC_P1, Ethernet Interface Connector The DC_P1 is a high speed SAMTEC connector allows the user to interface to the Ethernet logic on the TMS320DM6467 EVM. The pinout for the DC_P1 connector is shown in the table below. Table 16: DC_P1, Ethernet Interface Connector...
  • Page 54 3.2.28 DC_P2, Video Expansion Connector The DC_P2 is a 120 pin SAMTEC high speed connector allows the user to interface to the video logic on the TMS320DM6467 EVM. The pinout for the pins 1-60 of the DC_P2 connector are shown in the table below.
  • Page 55 Spectrum Digital, Inc The pinout for the pins 61-120 of the DC_P2 connector are shown in the table below. Table 18: DC_P2, Video Expansion Connector, Pins 61-120 Pin # Signal Pin # Signal GROUND GROUND UART1_CTSn UART1_RTSn UART1_TXD UART1_RXD GROUND...
  • Page 56 3.2.29 DC_P3, I/O Expansion Connector The DC_P3 connector allows the user to interface to the I/O logic on the TMS320DM6467 EVM. The pinout for the pins 1-60 of the DC_P3 connector are shown in the table below. Table 19: DC_P3, I/O Expansion Connector, Pins 1-60...
  • Page 57 Spectrum Digital, Inc The pinout for the pins 61-120 of the DC_P3 connector are shown in the table below. Table 20: DC_P3, I/O Expansion Connector, Pins 61-120 Pin # Signal Pin # Signal DC_HD26_EMA10 DC_HD27_EMA11 DC_HD24_EMA8 DC_HD25_EMA9 DC_HD22_EMA6 DC_HD23_EMA7 DC_HD20_EMA4...
  • Page 58 Spectrum Digital, Inc 3.3 LEDs The TMS320DM6467 EVM has SIX (6) LEDs. Four of these LEDs (DS1-4) are under user control and addressed over the I C bus. LED DS5 indicates the presence of +5 volts on the board. LED DS6 indicates the power has been turned on via SW4. The LED functions are summarized in the table below.
  • Page 59 Spectrum Digital, Inc 3.4.2 SW2, 4 Position User Readable Switch SW2 is a 4 position bank of user readable switches via the I C expander. The individual switches can be placed in any position and read by the user software from the expander.
  • Page 60 DM6467. These two positions are shown in the table below. Table 25: SW3, Position 6, PCI ON Side Function “0” Pin muxing defaults to EMIF or HPI Down “1” PCI pin multiplexing enabled on DM6467 3-30 TMS320DM6467 EVM Technical Reference...
  • Page 61 Spectrum Digital, Inc SW3, Position 7, is the DSP switch that allows the user to control the DSP booting. If the switch has the “ON” side pushed “DOWN” the DSP boots via EMIF A if ARM HPI or PCI boot mode is not enabled. When the switch has the “ON” side “UP” position the DSP is booted via the ARM.
  • Page 62 Table 28: S1, EMU0/1 Select State at Reset Function EMU0 EMU1 Emulation Debug ARM JTAG Enabled Not Defined Not Defined Emulation Debug * Both ARM & DSP JTAG Enabled * is the factory shipped configuration 3-32 TMS320DM6467 EVM Technical Reference...
  • Page 63 TP35,TP36 TP25 TP23,TP24 TP13,TP14 TP17-TP20 TP22 TP15,TP16 TP33,TP34 TP42 TP12 TP10 TP27 TP43,TP7 TP11 TP21,TP26 TP5,TP6 TP30-TP32 TP2,TP4 TP37-TP41 TP28-TP32 Figure 3-24, TMS320DM6467 EVM, Test Points 3-33...
  • Page 64 Spectrum Digital, Inc Table 29: TMS320DM6467 EVM Test Points Test Point # Signal Test Point # Signal GROUND TP23 VCC_3V3 TVP7002 HSYNC Output TP24 3.3 Volt Output GROUND TP25 3.# Volt Power Good TVP7002 SYNC Green Output TP26 TVP5147 (U26) Vertical...
  • Page 65 Appendix A Schematics This appendix contains the schematics for the TMS320DM6467 EVM.
  • Page 66 Spectrum Digital, Inc TMS320DM6467 EVM Technical Reference...
  • Page 67 Spectrum Digital, Inc...
  • Page 68 Spectrum Digital, Inc TMS320DM6467 EVM Technical Reference...
  • Page 69 Spectrum Digital, Inc...
  • Page 70 Spectrum Digital, Inc TMS320DM6467 EVM Technical Reference...
  • Page 71 Spectrum Digital, Inc...
  • Page 72 Spectrum Digital, Inc TMS320DM6467 EVM Technical Reference...
  • Page 73 Spectrum Digital, Inc...
  • Page 74 Spectrum Digital, Inc A-10 TMS320DM6467 EVM Technical Reference...
  • Page 75 Spectrum Digital, Inc A-11...
  • Page 76 Spectrum Digital, Inc A-12 TMS320DM6467 EVM Technical Reference...
  • Page 77 Spectrum Digital, Inc A-13...
  • Page 78 Spectrum Digital, Inc A-14 TMS320DM6467 EVM Technical Reference...
  • Page 79 Spectrum Digital, Inc A-15...
  • Page 80 Spectrum Digital, Inc A-16 TMS320DM6467 EVM Technical Reference...
  • Page 81 Spectrum Digital, Inc A-17...
  • Page 82 Spectrum Digital, Inc A-18 TMS320DM6467 EVM Technical Reference...
  • Page 83 Spectrum Digital, Inc A-19...
  • Page 84 Spectrum Digital, Inc A-20 TMS320DM6467 EVM Technical Reference...
  • Page 85 Spectrum Digital, Inc A-21...
  • Page 86 Spectrum Digital, Inc A-22 TMS320DM6467 EVM Technical Reference...
  • Page 87 Spectrum Digital, Inc A-23...
  • Page 88 Spectrum Digital, Inc A-24 TMS320DM6467 EVM Technical Reference...
  • Page 89 Spectrum Digital, Inc A-25...
  • Page 90 Spectrum Digital, Inc A-26 TMS320DM6467 EVM Technical Reference...
  • Page 91 Spectrum Digital, Inc A-27...
  • Page 92 Spectrum Digital, Inc A-28 TMS320DM6467 EVM Technical Reference...
  • Page 93 Spectrum Digital, Inc A-29...
  • Page 94 Spectrum Digital, Inc A-30 TMS320DM6467 EVM Technical Reference...
  • Page 95 Spectrum Digital, Inc A-31...
  • Page 96 Spectrum Digital, Inc A-32 TMS320DM6467 EVM Technical Reference...
  • Page 97 Spectrum Digital, Inc A-33...
  • Page 98 Spectrum Digital, Inc A-34 TMS320DM6467 EVM Technical Reference...
  • Page 99 Spectrum Digital, Inc A-35...
  • Page 100 Spectrum Digital, Inc A-36 TMS320DM6467 EVM Technical Reference...
  • Page 101 Spectrum Digital, Inc A-37...
  • Page 102 Spectrum Digital, Inc A-38 TMS320DM6467 EVM Technical Reference...
  • Page 103 Spectrum Digital, Inc A-39...
  • Page 104 Spectrum Digital, Inc A-40 TMS320DM6467 EVM Technical Reference...
  • Page 105 Spectrum Digital, Inc A-41...
  • Page 106 Spectrum Digital, Inc A-42 TMS320DM6467 EVM Technical Reference...
  • Page 107 Spectrum Digital, Inc A-43...
  • Page 108 Spectrum Digital, Inc A-44 TMS320DM6467 EVM Technical Reference...

  • Page 109: Mechanical Information

    Appendix B Mechanical Information This appendix contains the mechanical information about the TMS320DM6467 EVM produced by Spectrum Digital.
  • Page 110 Spectrum Digital, Inc TMS320DM6467 EVM Technical Reference...
  • Page 112 Printed in U.S.A., July 2007 509535-0001 Rev A...
