- Page 1 eZdsp F2804x Technical Reference 2006 DSP Development Systems...
- Page 3 F2804x Technical Reference 509165-0001 Rev. B November 2006 SPECTRUM DIGITAL, INC. 12502 Exchange Dr., Suite 440 Stafford, TX. 77477 Tel: 281.494.4505 Fax: 281.494.5310 sales@spectrumdigital.com www.spectrumdigital.com...
- Page 4 IMPORTANT NOTICE Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any product or service without notice. Customers are advised to obtain the latest version of relevant information to verify data being relied on is current before placing orders.
-
Page 5: Table Of Contents
Contents Introduction to the eZdsp F2804x ......... . . 1-1 Provides a description of the eZdsp F2804x, key features, and board outline. - Page 6 List of Figures Figure 1-1, Block Diagram eZdsp F2804x ........1-3 Figure 2-1, eZdsp F2804x PCB Outline .
- Page 7 About This Manual This document describes board level operations of the eZdsp F2804x based on the Texas Instruments TMS320F2804x Digital Signal Processor. The eZdsp F2804x is a stand-alone module permitting engineers and software developers evaluation of certain characteristics of the TMS320F2804x DSP to determine processor applicability to design requirements.
- Page 8 Table 1: Manual History Revision History Preliminary Release Table 2: Board History Revision History Prototype Release...
-
Page 9: Introduction To The Ezdsp Tm F2804X
Chapter 1 Introduction to the eZdsp F2804x This chapter provides a description of the eZdsp for the TMS320F2804x Digital Signal Processor, key features, and block diagram of the circuit board. Topic Page Overview of the eZdsp F2804x Key Features of the eZdsp F2804x Functional Overview of the eZdsp F2804x... - Page 10 Spectrum Digital, Inc 1.0 Overview of the eZdsp F2804x The eZdsp F2804x is a stand-alone card--allowing evaluators to examine the TMS320F2804x digital signal processor (DSP) to determine if it meets their application requirements. Furthermore, the module is an excellent platform to develop and run software for the TMS320F2804x processor.
-
Page 11: Tm F2804X
Spectrum Digital, Inc 1.2 Functional Overview of the eZdsp F2804x Figure 1-1 shows a block diagram of the basic configuration for the eZdsp F2804x. The major interfaces of the eZdsp are the JTAG interface, and expansion interface. 20 Mhz. XTAL1/OSCIN... - Page 12 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
-
Page 13: Operation Of The Ezdsp Tm F2804X
Chapter 2 Operation of the eZdsp F2804x This chapter describes the operation of the eZdsp F2804x, key interfaces and includes a circuit board outline. Topic Page The eZdsp F2804x Operation The eZdsp F2804x Board 2.1.1 Power Connector eZdsp F2804x Memory 2.2.1 Memory Map eZdsp... - Page 14 Spectrum Digital, Inc 2.0 The eZdsp F2804x Operation This chapter describes the eZdsp F2804x, key components, and operation. Information on the eZdsp’s various interfaces is also included. The eZdsp F2804x consists of four major blocks of logic: • Analog Interface Connector •...
- Page 15 Spectrum Digital, Inc 2.1.1 Power Connector The eZdsp F2804x is powered by a 5-Volt only power supply, included with the unit. The unit requires 500mA. The power is supplied via connector P6. If expansion boards are connected to the eZdsp, a higher amperage power supply may be necessary.
-
Page 16: Memory Map
Spectrum Digital, Inc 2.2.1 Memory Map The figure below shows the memory map configuration on the eZdsp F2804x. F2804x Block Start Address Data Space Program Space 0x0000-0000 M0 SARAM 0x0000-0400 M1 SARAM 0x0000-0800 Peripheral Frame 0 Do Not Use ! -
Page 17: Ezdsp Tm F2804X Connectors
Spectrum Digital, Inc 2.3 eZdsp F2804x Connectors The eZdsp F2804x has five connectors. Pin 1 of each connector is identified by a square solder pad. The function of each connector is shown in the table below: Table 1: eZdsp F2804x Connectors... -
Page 18: Figure 2-3, Ezdsp Tm F2804X Connector And Switch Positions
Spectrum Digital, Inc The diagram below shows the position of each connector J201 TMS320F2804x P5/P9 Figure 2-3, eZdsp F2804x Connector and Switch Positions eZdsp F2804x Technical Reference... -
Page 19: P1, Jtag Interface
Spectrum Digital, Inc 2.3.1 P1, JTAG Interface The eZdsp F2804x is supplied with a 14-pin header interface, P1. This is the standard interface used by JTAG emulators to interface to Texas Instruments DSPs. The positions of the 14 pins on the P1 connector are shown in the diagram below as viewed from the top of the eZdsp. -
Page 20: J201, Usb Port/Jtag Interface
Spectrum Digital, Inc 2.3.2 J201, USB Port/JTAG Interface The eZdsp F2804x uses a custom USB port JTAG interface device. The device has direct access to the integrated JTAG interface. Drivers for C2000 Code Composer tools are shipped with the eZdsp modules 2.3.3 P8, I/O Interface... - Page 21 Spectrum Digital, Inc The pin definition of P4/P8 connectors are shown in the table below. Table 3: P4/P8, I/O Connectors P8 Signal P8 Signal Pin # Pin # +3.3V/+5V/NC * +3.3V/+5V/NC * MUX_GPIO29 MUX_GPIO28 GPIO14 GPIO20 GPIO21 GPIO23 GPIO0 GPIO1...
-
Page 22: P5,P9, Analog Interface
Spectrum Digital, Inc 2.3.4 P5/P9, Analog Interface The position of the 30 pins on the P5/P9 connectors are shown in the diagram below as viewed from the top of the eZdsp. ANALOG Figure 2-6, Connector P5/P9 Pin Locations The definition of P5/P9 signals are shown in the table below. -
Page 23: P6, Power Connector
Spectrum Digital, Inc 2.3.5 P6, Power Connector Power (5 volts) is brought onto the eZdsp F2804x via the P6 connector. The connector has an outside diameter of 5.5 mm. and an inside diameter of 2.5 mm. The position of the P6 connector is shown below. -
Page 24: P10, Rs-232 Connector
Spectrum Digital, Inc 2.3.6 P10, RS-232 Connector The eZdsp F2804x has an RS-232 connector which brings out the SCIA transmit and receive signals to be used as UART. This UART uses the MAX3238 RS-232 line driver and is routed to a male 9 pin D-connector, P10. The pin positions for the P10 connector as viewed from the edge of the printed circuit board are shown below. -
Page 25: Connector Part Numbers
Spectrum Digital, Inc 2.3.7 Connector Part Numbers The table below shows the part numbers for connectors which can be used on the eZdsp F2804x. Part numbers from other manufacturers may also be used. Table 6: eZdsp F2804x Suggested Connector Part Numbers... -
Page 26: Jp4, Voltage Jumper, +3.3/5 Volts For
Spectrum Digital, Inc 2.4.1 JP4, Voltage Jumper, +3.3/5 Volts for P8, P4 Jumpers JP4 is an unpopulated jumper on the bottom side of the board that provide either +3.3 volts or +5 volts to pins on the expansion connector. This jumper is shipped uninstalled to prevent accidental damage by connecting wires or circuitry to the expansion connector. -
Page 27: Jp5, Adcrefin Select
Spectrum Digital, Inc 2.4.2 JP5, ADCREFIN Select Jumper J5 is used to select ADCREFIN as the voltage reference for the analog to digital converter. When the jumper is shorted the +2.048 voltage level is routed to the ADCREFIN signal of the DSP. When the jumper is open the ADCREFIN floats. -
Page 28: Switches
Spectrum Digital, Inc 2.5 Switches The eZdsp F2804x has 2 switches, SW1 and SW2, which are used to configure various functions on the board. The switches and their functionality are described in the following sections. 2.5.1 Switch SW1 The eZdsp F2804x has a 6 position switch, SW1, that allows the user to configure the board for their application. -
Page 29: Switch Sw1, Position 1-3, Boot Mode Select
Spectrum Digital, Inc 2.5.1.1 Switch SW1, Positions 1-3, Boot Mode Select Positions 1-3 on switch SW1 are used to determine what mode the DSP will use for bootloading on power up. The options are shown in the table below. Table 11: SW1, Positions 1-3... -
Page 30: Switch Sw1, Position 6, Serial Eeprom Address A1
Spectrum Digital, Inc 2.5.1.3 Switch SW1, Position 5, Serial EEPROM Pull-ups Position 5 on switch SW1 are used to select if the EEPROM is using pull up resistors. When position 5 is in the “Closed” state pull up resistors are used. When position 5 is in the “Open”... -
Page 31: Switch Sw2
Spectrum Digital, Inc 2.5.2 Switch SW2 Switch SW2 on the eZdsp F2804x has 4 positions that allow the user to configure the SCI MUX. The function of each position is shown in the table below. Table 15: SW2 Switch Positions... -
Page 32: Test Points
Spectrum Digital, Inc 2.7 Test Points The eZdsp F2804x has two test points. The signals they are tied to are shown in the table below. Table 17: Test Points Test Point Signal Analog Ground Ground 2-20 eZdsp F2804x Technical Reference... -
Page 33: A Ezdsp Tm F2804X Schematics
Appendix A eZdsp F2804x Schematics The schematics for the eZdsp F2804x can be found on the CD-ROM that accompanies this board. The schematics were drawn on ORCAD. WARNING ! The TMS320F2804x supports +3.3V Input/Output levels which are NOT +5V tolerant. Connecting the eZdsp to a system with +5V Input/Output levels will damage the TMS320F2804x. - Page 34 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
- Page 35 Spectrum Digital, Inc...
- Page 36 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
- Page 37 Spectrum Digital, Inc...
- Page 38 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
- Page 39 Spectrum Digital, Inc...
- Page 40 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
-
Page 41: B Ezdsp Tm F2804X Mechanical Information
Appendix B eZdsp F2804x MechanicaI Information This appendix contains the mechanical information about the socketed and unsocketed versions of the eZdsp F2804x. - Page 42 Spectrum Digital, Inc eZdsp F2804x Technical Reference...
- Page 44 Printed in U.S.A., November 2006 509165-0001 Rev. B...
