3.2.23 P9, PCI Connector
The P9 connector is a card edge PCI interface. This connector has an "A" and "B" side.
Because of the card seating notches the pin numbers are not contiguous. The "B" side
is the top component side. The I/O direction field is referenced from the PCI slot.
Pin Signal
1 TRST-
3 TMS
5 +5 Volts
7 INTC-
9 Rsvd.0
11 Rsvd.1
13 Key.2
15 RST-
17 GNT-
19 PME-
21 +3.3 Volts
23 AD26
25 AD24
27 +3.3 Volts
29 AD20
31 AD18
33 +3.3 Volts
35 GND
37 GND
39 +3.3 Volts
41 SBO-
43 PAR
45 +3.3 Volts
47 AD11
49 AD9
51 Key.4
53 +3.3 Volts
55 AD4
57 AD2
59 +V I/O
61 +5 Volts
3-18
Table 12: P9, PCI Connector, "A" Side
I/O Description
Not Used
Not Used
+5 Volts Power
O Interrupt Out
Not Used
Not Used
Key
I PCI_Resetn
O Grant-
Not Used
I/O/Z Address/Data 26
I/O/Z Address/Data 24
Not Used
I/O/Z Address/Data 20
I/O/Z Address/Data 18
Not Used
Ground
Ground
Not Used
I/O/Z Parity
Not Used
I/O/Z Address/Data 11
I/O/Z Address/Data 9
Key
Not Used
I/O/Z Address/Data 4
I/O/Z Address/Data 2
Not Used
+5 Volts Power
Pin Signal I/O
2 +12 Volts
4 TDI I/O
6 INTA- O
8 +5 Volts
10 +V I/O
12 Key.1
14 +3.3 Vaux
16 +V I/O O
18 GND
20 AD30 I/O/Z
22 AD28 I/O/Z
24 GND
26 IDSEL I
28 AD22 I/O/Z
30 GND
32 AD16 I/O/Z
34 FRAME- I
36 TRDY- I/O/Z
38 STOP- I/O/Z
40 SDONE O
42 GND
44 AD15 I/O/Z
46 AD13 I/O/Z
48 GND
50 Key.3
52 C/BE0
54 AD6 I/O/Z
56 GND
58 AD0 I/O/Z
60 REQ64-
62 +5 Volts
TMS320DM6467 EVM Technical Reference
Description
Not Used
Tied to TDO
Interrupt Out
+5 Volts Power
Not Used
Key
Not Used
Not Used
Ground
Address/Data 30
Address/Data 28
Initialization Device Select
Address/Data 22
Ground
Address/Data 16
Frame
Target Ready
Stop Direction
Done
Ground
Address/Data 15
Address/Data 13
Ground
Key
Command/Byte Enable0
Address/Data 6
Ground
Address/Data 0
Not Used
+5 Volts Power
