- Page 1 XDS560v2 LC Traveler JTAG Emulator Technical Reference 2011 DSP Development Systems...
- Page 3 XDS560v2 LC Traveler JTAG Emulator Technical Reference 515325-0001 Rev. A December 2011 SPECTRUM DIGITAL, INC. 12502 Exchange Drive, #440 Stafford, TX. 77477 Tel: 281.494.4500 Fax: 281.494.5310 sales@spectrumdigital.com www.spectrumdigital.com...
- Page 4 IMPORTANT NOTICE Spectrum Digital, Inc. reserves the right to make changes to its products or to discontinue any product or service without notice, and advises its customers to obtain the latest version of relevant information to verify, before placing orders, that the information being relied on is current.
-
Page 5: Table Of Contents
......Lists the hardware and software you’ll need to install the XDS560v2 LC Traveler JTAG Emulator, and the installation procedure of the XDS560v2 LC Traveler in your system. - Page 6 JTAG Emulator. This emulator is designed to be used with digital signal processors (DSPs) and microcontrollers designed by Texas Instruments. The XDS560v2 LC Traveler JTAG Emulator is a table top module that attaches to a personal computer or laptop to allow hardware engineers and software programmers to develop applications with DSPs and microcontrollers.
-
Page 7: Introduction To The Xds560V2 Lc Traveler Jtag Emulator
Chapter 1 Introduction to the XDS560v2 LC Traveler JTAG Emulator This chapter provides you with a description of the XDS560v2 LC Traveler JTAG Emulator along with the key features. Topic Page Overview of the XDS560v2 LC Traveler JTAG Emulator Key Features of the XDS560v2 LC Traveler JTAG... - Page 8 Spectrum Digital, Inc 1.0 Overview of the XDS560v2 LC Traveler JTAG Emulator The XDS560v2 LC Traveler JTAG Emulator is designed to be used with digital signal processors (DSPs) and microprocessors which operate from +1.2 to +4.1 volt levels on the JTAG interface. The power for the emulator comes from the USB interface on a PC/laptop/USB hub.
-
Page 9: Key Items On The Xds560V2 Lc Traveler
Spectrum Digital, Inc 1.2 Key Items on the XDS560v2 LC Traveler JTAG Emulator Figure 1-1 shows the XDS560v2 LC Traveler. The key items identified are: • Status LEDs • JTAG Header • Emulator Tail Assembly • USB connector to the host PC or hub... - Page 10 Spectrum Digital, Inc THIS PAGE IS INTENTIONLY LEFT BLANK ! XDS560v2 LC Traveler JTAG Emulator Technical Reference...
-
Page 11: Installing The Xds560V2 Lc Traveler Jtag Emulator
Chapter 2 Installing the XDS560v2 LC Traveler JTAG Emulator This chapter helps you install the XDS560v2 LC Traveler JTAG Emulator. For use with specific software packages such as the TI’s Code Composer Studio refer to their respective documentation. Topic Page What You’ll Need... -
Page 12: Hardware Checklist
Spectrum Digital, Inc What You’ll Need The following checklists detail items that are shipped with the XDS560v2 LC Traveler JTAG emulator and additional items you’ll need to use these tools. Hardware checklist __ host computer An IBM PC/AT or 100% compatible PC or laptop running Windows... -
Page 13: Installing The Xds560V2 Lc Traveler Jtag Emulator
Spectrum Digital, Inc 2.2 Installing the XDS560v2 LC Traveler JTAG Emulator The next three sections describe the steps for installing the XDS560v2 LC Traveler JTAG Emulator to interface to a PC or laptop via USB. WARNING ! Target Cable Connectors: Be very careful with the target cable connectors. - Page 14 Spectrum Digital, Inc The female JTAG connector attached to the end of the emulator tail plugs onto the target’s male pin header. The figure below shows how the XDS560v2 LC Traveler emulator header plugs onto the target’s JTAG header Emulator Tail...
- Page 15 Tail Header CTI20 JTAG Header 14 Pin JTAG header Figure 2-2, 14 Pin TI JTAG plugs into CTI20 Header The adapter that comes with the XDS560v2 LC Traveler are shown in the figure below. Tail Header CTI20 - TI14 Adapter...
-
Page 16: Xds560V2 Lc Traveler Installation Checklist
Turn off the power to your target board. The XDS560v2 LC Traveler must be connected to the host PC via USB. Connect the supplied USB cable to a USB port on your PC or laptop. The XDS560v2 LC Traveler may be used with a powered USB hub. - Page 17 Caution should be used in the routing of the tail ribbon cable to insure it does not go near the processor(s), power traces, or power cords. 20 Pin 14 Pin Align the emulator tail over the target connector, then push down Emulator tail attached to target Figure 2-5, Attaching the XDS560v2 LC Traveler Emulator Tail To Target...
- Page 18 Your system configuration should be similar to the one in Figures 2-6 and 2-7. Figure 2-6 shows a typical configuration in which the XDS560v2 LC Traveler can be used with a host PC and target board via the USB interface.
- Page 19 Spectrum Digital, Inc Figure 2-7 shows a typical configuration in which the XDS560v2 LC Traveler can be used with a host PC and target board via the USB Hub interface 110/220 VAC Power Plugs into USB port Supply on Hub and PC/Laptop USB Hub ~ ! @ # $ % ^ &...
-
Page 20: Xds560V2 Lc Traveler Leds
STATE-1 Green Off = CCS disconnected * On the XDS560v2 LC Traveler the internal FPGA programming is deferred to the first target connection. This is a minor difference between the standard XDS560v2 and is done to conserve power. XDS560v2 LC Traveler JTAG Emulator Technical Reference... -
Page 21: Xds560V2 Lc Traveler Leds During Boot
The following sequences with approximate timings are provided for reference. From the sequences you can see that it may take the XDS560v2 LC Traveler around 40 seconds to boot so during this time do not power cycle the unit. - Page 22 Spectrum Digital, Inc THIS PAGE IS INTENTIONALLY LEFT BLANK ! XDS560v2 LC Traveler JTAG Emulator Technical Reference 2-12...
-
Page 23: Specifications For Your Target System's Connection To The Emulator
Specifications For Your Target System’s Connection to the Emulator This chapter contains information about connecting the XDS560v2 LC Traveler JTAG emulator to your target system. The emulator tail may plug directly onto the target board or use an intermediate adapter. - Page 24 Spectrum Digital, Inc 3.1 Designing Your Target System’s Emulator Connector The XDS560v2 LC Traveler JTAG emulator tail provides the CTI 20 pin interface. If your target board cannot use or accommodate this connector a target adapter will be required. A CTI20 to TI14 pin adapter comes with the XDS560v2 LC Traveler.
- Page 25 If your target board has a 14 pin JTAG header it should be laid out as shown in the figure below. If your board does have a 14 pin header you should use the CTI20 to TI14 pin adapter that came with the XDS560v2 LC Traveler. 0.1 inch 0.1 inch...
- Page 26 All numbers are in inches. 0.24 0.31 0.44 CTI20 Pin Connector Height (typical) 0.24 1.00 0.55 TI14 Pin Connector Height (typical) Figure 3-3, XDS560v2 LC Traveler Emulator Tail Heights XDS560v2 LC Traveler JTAG Emulator Technical Reference...
-
Page 27: Appendix A Mechanical Information
Appendix A Mechanical Information This appendix contains the mechanical information about the XDS560v2 LC Traveler JTAG Emulator produced by Spectrum Digital. - Page 28 Spectrum Digital, Inc The figure below provides the physical dimensions of the XDS560v2 LC Traveler JTAG emulator. Figure A-1, XDS560v2 LC Traveler Dimensions Note: All dimensions are in inches and are nominal dimensions, unless otherwise specified. XDS560v2 LC Traveler JTAG Emulator Technical Reference...
- Page 29 Spectrum Digital, Inc The figure below provides the physical dimensions of the XDS560v2 LC Traveler JTAG tail header and adapter. 0.24 0.31 0.44 CTI20 Pin Connector Height (typical) 0.24 1.00 0.55 TI14 Pin Connector Height (typical) Figure A-2, XDS560v2 LC Traveler Emulator Tail Heights Note: All dimensions are in inches and are nominal dimensions, unless otherwise specified.
- Page 30 Spectrum Digital, Inc THIS PAGE IS INTENTIONALLY LEFT BLANK ! XDS560v2 LC Traveler JTAG Emulator Technical Reference...
- Page 32 Printed in U.S.A., December 2011 515325-0001 Rev A...
